- Page 1 INSTRUCTION MANUAL Multicolor Art Glass 1-Light Pendant Home Depot Stock SKU 542-293 Special Order SKU 542-590 (UPC 092903283512) Page 1...
- Page 2 Thank you for purchasing this Hampton Bay interior pendant fixture. This product has been manufactured to the highest standards of safety and quality. The durable finish and glass shade provide for care -free maintenance. Simply wipe with a clean towel to keep looking new.
-
Page 3: Tools Required For Assembly
TOOLS REQUIRED FOR ASSEMBLY: Phillips screwdriver Flathead screwdriver (not included) (not included) Light Bulb (not included) (40-watt maximum candelabra base bulb or CFL equivalent) PARTS INCLUDED FOR ASSEMBLY (parts are not to scale): 3 ea –Wire Nut (C) 2 ea – Mounting 1 ea –... - Page 4 ASSEMBLY INSTRUCTIONS 1. TURN OFF ELECTRICITY at main fuse box (or circuit breaker box) before beginning installation by Ground supply wire switching circuit breaker off or removing fuse. MIN 90º C SUPPLY CONDUCTORS. CONSULT A Black (hot) Ground fixture wire QUALIFIED ELECTRICIAN TO ENSURE COR- RECT BRANCH CIRCUIT CONDUCTOR.
-
Page 5: Troubleshooting
TROUBLESHOOTING: Possible Cause Corrective Action Bulb will not light. 1. Bulb is burned out. 1. Replace light bulb. 2. Power is off. 2. Make sure power supply is on. 3. Cord not plugged in. 3. Make sure cord is plugged into the outlet. 4. - Page 6 MANUAL DE INSTRUCCIONES Lámpara colgante con cristal artistico multicolor de 1 luz Home Depot Stock SKU 542-293 Pedido especial SKU 542-590 (UPC 092903283512) Page 6...
- Page 7 Antes de devolver el producto a The Home Depot, llama por favor a nuestro Equipo de Servi- cio al Cliente al 1-877-385-2907 o visita www.homedepot.com. Usa como referencia el stock SKU numero 542-293 y para pedido especial SKU 542-590 cuando hables con un agente de servicio al cliente.
-
Page 8: Herramientas Necesarias Para El Ensamblaje
HERRAMIENTAS NECESARIAS PARA EL ENSAMBLAJE: Destornillador Phillips Destornillador de cabeza plana (no incluidos) (no incluidos) Bombilla (no incluida) (No mayor de 40 vatios de base candelabro o equivalente CFL) PIEZAS INCLUIDAS PARA EL ENSAMBLAJE (no se muestran a escala): (2) Mounting (1) Soporte de (2) Tornillos de la (3) Tuercas para... - Page 9 INSTRUCCIONES DE ENSAMBLAJE 2. Para ajustar el largo del cordón, afloje el tornillo en el aseguraror del cordón deslizando el cordón a través Cable de suministro a tierra del mismo para acortar o alargar el cordón como se Negro (positivo) desee.
-
Page 10: Solución De Problemas
SOLUCIÓN DE PROBLEMAS: Causa Posible Solución La bombilla no 1. La bombilla está 1. Reemplaza la bombilla. enciende. fundida. 2. No hay electricidad. 2. Asegúrate de que la corriente esté encendida. 3. El cable no está 3. Asegúrate de que el enchufado.
