Seypos PRP-310 Quick Installation Manual

PRP-310
Thermal Receipt Printer
Quick Installation Guide
Specification
Model PRP-310
Print Method Thermal line printing
Print Speed 250mm/sec
Print Life 100 Km
ANK Font.
ASCII Mode
Print
Font A: 12 x 24 dots, Font B: 9 x 17 dots
Font
Graphic Font Chinese Character: 24 x 24 dots
Print Resolution 576 dots/line or 512 dots/line
Print Font Character
International Font, Big 5 Chinese, GB Chinese
Support
Character Per Line 48 (Font A)/42 (Font B)
Effective Print Width 72mm
Paper Width 79.5mm± 0.5mm
Paper Roll Diameter ≦ 83mm
Paper Thickness 0.06~0.08mm
Win 9X/Win ME/Win 2000/Win 2003/Win NT/Win XP/
Driver Win Vista/Win 7/Win 8/Win 10,
compatible with EPSON
Print Command ESC/POS print commands set compatible
Interface
Multi I/O Interface:
Interface
Serial +Ethernet +USB (UTP)
Cash Drawer +24VDC/1A, 6-Wire RJ-11
Notification
Indicator Audio and LED Indicators
Auto Cutter Partial
Paper End Notice Yes
Over-Heat Protection Yes
Others
+24VDC/2.5A
Power Input
(External Adapter: 100 ~ 240VAC, 50/60Hz)
Color Black
Compliance FCC, CE, WEEE, RoHS
Weight 1200g
Dimension (mm) 183.5(L) x 140(W) x 126(H)
Operating Temperature 0°C ~ 45°C
Operating Humidity 10% ~ 80% RH, non-condensing
Storage Temperature -10°C ~ 60°C
Storage Humidity 10% ~ 90% RH, non-condensing
* All specifications are subject to change without prior notice.
Product Overview
TOP
Bottom
Front Side
Rear
(USB+RS-232+Ethernet)
Contents
Printer Unit Power Adaptor *Power Cord
**Printer Cable Paper Roll Paper Roll
Holder
Quick Installation
Paper Width
Guide Guide
* Power Cord is selectable depending on the types of electrical plug.
** Printer cable is selectable depending on the interface required
(RS-232, USB, RJ-45).
Please refer to the nearest local representatives for further information.
Installing your Printer
Power Adapter
Power Cord
Printer
RS-232 USB
RS-232 RJ-11 Power USB
Cash
Drawer
Installing the Paper Roll
Paper Roll
and
Paper Roll Holder
Printer Cable
Ethernet (RJ-45)
RJ-11 Power RJ-45 RJ-11Power
Cash Cash
Drawer Drawer
Paper Roll
Holder
Paper Roll
Paper Roll
Holder
HOST PC
Paper Roll
Paper Width
Guide
