ASSEMBLY INSTRUCTIONS
Please provide the following information when contacting for parts or questions: the name of the
company you purchased from, the tracking number of the original package, and the original order date.
We offer free replacements for 1 year (purchase verification required). This replacement policy does
not cover used/previously returned product or products sold by unauthorized third party vendors.
Carefully unpack & identify each component before attempting to assemble. Refer to parts list.
Please take care when assembling the unit and always set the parts on a clean, soft surface. If you
require any assistance with assembly, parts, please call the company you place order with or please
email to:service@eleganthf.net
INSTRUCCIONES PARA ARMAR‐IMPORANT:
Desempaque cuidadosamente e identifique cada
componente antes de tartar de empezar su
ensambladura. Verifique la lista de partes. Por favor
tenga cuidado cuando arme la unidad y siempre
coloque las piezas sobre una superficie plana, suave y
limpia. Si necesita ayuda con el armado, envie un
correo electzórico a service@eleganthf.net
EHF
LT 1D 2DR
ASSEMBLY INSTRUCTIONS‐IMPORTANT
DIRECTIVES DE MONTAGE‐IMPORTANT:
Avant de commencer l' assemblage, déballez
délicatement toutes les pièces et repérez‐les sur la
liste des pièces. Procédez avec soins durant l'
assemblage et posez toujours les pièces sur une
surface proper, douce et lisse. sie vouo plait e‐mail á
service@eleganthf.net
Advertisement
Related Manuals for EHF LT 1D 2DR
Summary of Contents for EHF LT 1D 2DR
- Page 1 ASSEMBLY INSTRUCTIONS LT 1D 2DR Please provide the following information when contacting for parts or questions: the name of the company you purchased from, the tracking number of the original package, and the original order date. We offer free replacements for 1 year (purchase verification required). This replacement policy does not cover used/previously returned product or products sold by unauthorized third party vendors. ASSEMBLY INSTRUCTIONS‐IMPORTANT Carefully unpack & identify each component before attempting to assemble. Refer to parts list. Please take care when assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts, please call the company you place order with or please email to:service@eleganthf.net INSTRUCCIONES PARA ARMAR‐IMPORANT: DIRECTIVES DE MONTAGE‐IMPORTANT: Desempaque cuidadosamente e identifique cada Avant de commencer l' assemblage, déballez componente antes de tartar de empezar su délicatement toutes les pièces et repérez‐les sur la ensambladura. Verifique la lista de partes. Por favor liste des pièces. Procédez avec soins durant l' tenga cuidado cuando arme la unidad y siempre assemblage et posez toujours les pièces sur une coloque las piezas sobre una superficie plana, suave y surface proper, douce et lisse. sie vouo plait e‐mail á limpia. Si necesita ayuda con el armado, envie un service@eleganthf.net correo electzórico a service@eleganthf.net...
- Page 2 Pg 1 of 12...
- Page 3 COMPONENTS PART FIGURE DESCRIPTION PART FIGURE DESCRIPTION TOP PANEL UPPER BACK PANEL 2PCS UPPER LEFT BOTTOM BACK 2PCS SIDE PANEL PANEL UPPER RIGHT BOTTOM SIDE PANEL PLASTIC BAR UPPER MIDDLE PANEL PLASTIC BAR DRAWER FACE DRAWER SHELF 2PCS PANEL DRAWER LEFT BOTTOM PANEL 2PCS SIDE PANEL...
-
Page 4: Hardware & Tools
HARDWARE & TOOLS PART FIGURE DESCRIPTION PART FIGURE DESCRIPTION CAM BOLT 16PCS DRAWER STOPPER 4PCS CAM LOCK 16PCS HANDLE 3PCS 15*12 ∅ WOODEN DOWEL 16PCS BOLT 6PCS 8*30 ∅ WOODEN DOWEL 4PCS FIX BELT 6*30 ∅ SCREW 6PCS SCREW 2PCS 3*14 4*25 ∅... - Page 5 4 PCS 8 PCS 6*30 ∅ STEP 1: 1. Screw Legs T into panel F. 2. Screw cambolts (1) and insert dowels (4) to panel F. 3. Attach panel E to side panels H & I with dowels (4) as indicated. Pg 4 of 12...
- Page 6 8 PCS 15*12 ∅ 8 PCS 8 PCS 8*30 ∅ STEP 2: 1. Attach panel F to the bottoms of panels H & I and secure with cambolts (1). 2. Screw cambolts (1) and insert dowels (3) to panel D as indicated. 3.
- Page 7 15*12 ∅ 4 PCS 4 PCS 8*30 ∅ STEP 3: 1. Attach panels B & C to the panel D and secure with camlocks (2) as indicated. 2. Insert dowels (3) to the tops of panel B & C. Pg 6 of 12...
- Page 8 4 PCS 15*12 ∅ 4 PCS STEP 4: 1. Screw cambolts (1) to the panel A. 2. Attach panel A to the tops of panels B & C and secure with camlocks (2). Pg 7 of 12...
- Page 9 32 PCS STEP 5: 1. Attach panels K to the back of the cabinet & secure the four corners with screws (6). 2. Insert plastic bar N between the two panel Ks and finish securing the panels with screws (6). 3.
- Page 10 6 PCS 3*14 ∅ 12 PCS 1 PC 2 PCS STEP 6: 1. Attach handle (10) to doors J with bolts (11). 2. Attach door J to panel C with screws (5). 3. Insert shelf pins (7) in panels B& C and rest the glass shelf G on the shelf pins. Pg 9 of 12...
- Page 11 16 PCS 4*25 ∅ 2 PCS 4 PCS STEP 7: 1. Attach panels P & Q to panel O and secure with screws (8). 2. Slide panel S into the panels O 、 P & Q as indicated. 3. Attach panel R to panels O 、 P & Q and secure with screws (8). 4.
- Page 12 4 PCS STEP 8: 1. Insert drawer into the cabinet and insert the drawer stoppers (9) as indicated. Pg 11 of 12...
- Page 13 1 PC 2 PCS 4*25 ∅ 2 PCS 1 PC Pg 12 of 12...
