ASSEMBLY INSTRUCTIONS
Please provide the following information when contacting for parts or questions: the name of the
company you purchased from, the tracking number of the original package, and the original order date.
We offer free replacements for 1 year (purchase verification required). This replacement policy does
not cover used/previously returned product or products sold by unauthorized third party vendors.
Carefully unpack & identify each component before attempting to assemble. Refer to parts list.
Please take care when assembling the unit and always set the parts on a clean, soft surface. If you
require any assistance with assembly, parts, please call the company you place order with or please
email to:service@eleganthf.net
INSTRUCCIONES PARA ARMAR‐IMPORANT:
Desempaque cuidadosamente e identifique cada
componente antes de tartar de empezar su
ensambladura. Verifique la lista de partes. Por favor
tenga cuidado cuando arme la unidad y siempre
coloque las piezas sobre una superficie plana, suave y
limpia. Si necesita ayuda con el armado, envie un
correo electzórico a service@eleganthf.net
EHF
FC w/3 Shelves
ASSEMBLY INSTRUCTIONS‐IMPORTANT
DIRECTIVES DE MONTAGE‐IMPORTANT:
Avant de commencer l' assemblage, déballez
délicatement toutes les pièces et repérez‐les sur la
liste des pièces. Procédez avec soins durant l'
assemblage et posez toujours les pièces sur une
surface proper, douce et lisse. sie vouo plait e‐mail á
service@eleganthf.net
Advertisement
Related Manuals for EHF FC w/3 Shelves
Summary of Contents for EHF FC w/3 Shelves
- Page 1 ASSEMBLY INSTRUCTIONS FC w/3 Shelves Please provide the following information when contacting for parts or questions: the name of the company you purchased from, the tracking number of the original package, and the original order date. We offer free replacements for 1 year (purchase verification required). This replacement policy does not cover used/previously returned product or products sold by unauthorized third party vendors. ASSEMBLY INSTRUCTIONS‐IMPORTANT Carefully unpack & identify each component before attempting to assemble. Refer to parts list. Please take care when assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts, please call the company you place order with or please email to:service@eleganthf.net INSTRUCCIONES PARA ARMAR‐IMPORANT: DIRECTIVES DE MONTAGE‐IMPORTANT: Desempaque cuidadosamente e identifique cada Avant de commencer l' assemblage, déballez componente antes de tartar de empezar su délicatement toutes les pièces et repérez‐les sur la ensambladura. Verifique la lista de partes. Por favor liste des pièces. Procédez avec soins durant l' tenga cuidado cuando arme la unidad y siempre assemblage et posez toujours les pièces sur une coloque las piezas sobre una superficie plana, suave y surface proper, douce et lisse. sie vouo plait e‐mail á limpia. Si necesita ayuda con el armado, envie un service@eleganthf.net correo electzórico a service@eleganthf.net...
- Page 2 Pg 1 of 12...
- Page 3 COMPONENTS PART FIGURE DESCRIPTION PART FIGURE DESCRIPTION DRAWER TOP PANEL LEFT SIDE PANEL DRAWER LEFT SIDE PANEL RIGHT SIDE PANEL DRAWER MIDDLE PANEL BACK PANEL DRAWER RIGHT SIDE PANEL BOTTOM PANEL FIX SHELF DOOR ADJUSTABLE SHELF BOTTOM PANEL 2PCS ADJUSTABLE SHELF BACK PANEL 2PCS PLASTIC BAR...
-
Page 4: Hardware & Tools
HARDWARE & TOOLS PART FIGURE DESCRIPTION PART FIGURE DESCRIPTION CAM LOCK 16PCS WASHER 2PCS 15*12 ∅ CAM BOLT 16PCS SHELF PIN 12PCS WOODEN DOWEL 16PCS SCREW 16PCS 8*30 3*12 D=7 ∅ ∅ SCREW 12PCS FIX BELT 4*25 ∅ SCREW 4PCS SCREW 2PCS 3*12... - Page 5 10 PCS 10 PCS STEP 1: 1. Screw cambolts (2) and insert dowels (3) to panel C & D. 2. Screw Legs Q into panel F. 3. Screw cambolts (2) and insert dowels (3) to panel F as indicated. Pg 4 of 12...
- Page 6 15*12 ∅ 10 PCS STEP 2: 1. Attach panel E to side panels C & D and secure with camlocks (1). 2. Attach panel B, C, D to panel F and secure with camlocks (1) as indicated. Pg 5 of 12...
- Page 7 6 PCS 6 PCS STEP 3: 1. Screw cambolts (2) to panel A. 2. Insert dowels (3) to the tops of panels B, C, & D. Pg 6 of 12...
- Page 8 15*12 ∅ 6 PCS STEP 4: 1. Attach panel A to panels B, C, & D and secure with camlocks (1). Pg 7 of 12...
- Page 9 16 PCS 3*12 D=7 ∅ STEP 5: 1. Attach panels G to the back of the cabinet & secure the four corners with screws (10). 2. Insert plastic bar H between the two panel Gs and finish securing the panels with screw (10).
- Page 11 4*25 10 PCS ∅ 1 PC STEP 7: 1. Attach handle (6) to panel I with screws (4). 2. Attach panels J & K to panel I and secure with screws (4). 3. Slide panel M into the panels J 、 K & I as indicated. 4.
- Page 13 2 PCS 1 PC 2 PCS 4*25 ∅ 1 PC Pg 12 of 12...
