L+ & L-
AO+ & AO-
Central terminal
_____________________________________________________________________________________
STI S.r.l. – Via Dei Caravaggi 15, 24040 Levate (BG) – ITALY
Manual 9031, rev. 02 27/02/2018 – FTC
Figure 4 – FTC-I Terminal Board XT1
Power connection (from Associated Apparatus)
Optional Analogue Output (to Associated Apparatus)
Earth / Ground
