- Page 1 Smart Positioner Series FTC-I FasTrak Compact SAFETY MANUAL 9031 INSTRUCTIONS - INSTALLATION, USE AND MAINTENANCE ADDITIONAL INSTRUCTIONS 4049(Ex)/IST...
- Page 2 Description Compiled Approved STI S.r.l has taken every care in collecting and verifying the documentation contained in this Instruction Manual. The information herein contained are reserved property of STI S.r.l. ____________________________________________________________________________________ STI S.r.l. – Via Dei Caravaggi 15, 24040 Levate (BG) – ITALY www.imi-critical.com...
- Page 3 INDEX SAFETY INSTRUCTIONS ........................1 RATED CHARACTERISTICS ....................... 3 COMMISSIONING..........................5 MAINTENANCE ............................ 6 ____________________________________________________________________________________ STI S.r.l. – Via Dei Caravaggi 15, 24040 Levate (BG) – ITALY www.imi-critical.com Manual 9031, rev. 02 27/02/2018 – FTC...
- Page 4 ____________________________________________________________________________________ STI S.r.l. – Via Dei Caravaggi 15, 24040 Levate (BG) – ITALY www.imi-critical.com Manual 9031, rev. 02 27/02/2018 – FTC...
-
Page 5: Safety Instructions
X4 connection facilities is restricted to use in a non-hazardous area following the below 2 indication: Only the ‘FTx positioner connection cable’ can be used. _____________________________________________________________________________________ STI S.r.l. – Via Dei Caravaggi 15, 24040 Levate (BG) – ITALY www.imi-critical.com Manual 9031, rev. 02 27/02/2018 – FTC - 1 -... - Page 6 Issue); all Intrinsically Safe circuits shall be included in Descriptive System Documents (EN IEC 60079-14, art. 4.2 and EN IEC 60079-25, art. 4). _____________________________________________________________________________________ STI S.r.l. – Via Dei Caravaggi 15, 24040 Levate (BG) – ITALY www.imi-critical.com Manual 9031, rev. 02 27/02/2018 – FTC...
-
Page 7: Rated Characteristics
(*) X = Temperature Class vs. Ta : 60°C = T5 ; 80°C = T4 Figure 3 – FTC-I Smart Positioner _____________________________________________________________________________________ STI S.r.l. – Via Dei Caravaggi 15, 24040 Levate (BG) – ITALY www.imi-critical.com Manual 9031, rev. 02 27/02/2018 – FTC - 3 -... - Page 8 Power connection (from Associated Apparatus) AO+ & AO- Optional Analogue Output (to Associated Apparatus) Central terminal Earth / Ground _____________________________________________________________________________________ STI S.r.l. – Via Dei Caravaggi 15, 24040 Levate (BG) – ITALY www.imi-critical.com Manual 9031, rev. 02 27/02/2018 – FTC - 4 -...
-
Page 9: Commissioning
5. Check that the Positioner is connected to the Associated Apparatus (1 per channel) provided for in the corresponding Descriptive System Document. _____________________________________________________________________________________ STI S.r.l. – Via Dei Caravaggi 15, 24040 Levate (BG) – ITALY www.imi-critical.com Manual 9031, rev. 02 27/02/2018 – FTC... -
Page 10: Maintenance
3. The replacement of any part of the Positioner series FTC-I shall be done with original parts supplied by STI S.r.l. 4. The use of Positioners that have undergone work not authorized by STI S.r.l. absolves STI S.r.l. from all liability and invalidates the relative warranty. - Page 11 _____________________________________________________________________________________ STI S.r.l. – Via Dei Caravaggi 15, 24040 Levate (BG) – ITALY www.imi-critical.com Manual 9031, rev. 02 27/02/2018 – FTC - 7 -...
- Page 12 IMI STI - Headquarters Via Dei Caravaggi 15 24040 Levate (BG) Italy Tel. +39 035 2928.2 Fax +39 035 2928.247 IMI Critical Engineering Lakeside, Solihull Parkway Birmingham Business Park Birmingham B37 7XZ United Kingdom Tel. +44 (0)121 717 3700 Fax +44 (0)121 717 3701 www.imi-critical.com...
