Technical Specifications
Power supply
Power over Ethernet (PoE),
typ. 48VDC
IEEE 802.3af Alternative A,
power class 0
Power consumption
typ. 1.7W, max. 4.25W
Ethernet interface
100 MBit/s
Voltage output for
24VDC, max. 3W
supplying external devices
Wire length: max. 3m / 10ft
(NFC Code Touch...)*
Tree interface
Connection of up to 50 Tree
devices
Wire length: max. 3m / 10ft
Ambient temperature
-20 ... +40 °C / -4 ... +104 °F
Humidity
max. 95% r.H. (non condensing)
IP34
Protection class
Dimensions
90x90x16mm /
3.55x3.55x0.63" (LxWxH)
Maintenance & Cleaning
This device is free of main-
tenance and may only be
cleaned with a dry cloth.
* The devices connected to the 24V power output and the Tree interface of
the Intercom must remain independent of the rest of the installation. No
connection to other Tree branches, power supplies or devices may be
established, not even via the GND.
Installation & electrical connection
The installation of this device has to be carried out by a
qualified person. The device has to be fitted in accordance
with building regulations for electrical and fire safety. If the
device is not installed according to manufacturers
guidelines the protection of the device may be affected.
This folder is a part of the product!
For additional information,
declaration of confirmity, visit
loxone.com/help/intercom
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
Loxone UK
The Forum,
Station Road,
Theale, RG7 4RA
loxone.com
Intercom
Part No: 100484 (White)
Part No: 100485 (Anthracite)
