Technical Specifications
Power supply
Power over Ethernet (PoE),
typ. 48VDC
IEEE 802.3af Alternative A,
power class 0
Power consumption
typ. 1.7W, max. 4.25W
Power supply output for
24VDC, max. 3W
peripheral devices (e.g. NFC
Code Touch)
Ethernet interface
100 MBit/s
Tree interface
Connect up to 50 Tree devices
Ambient temperature
-20 ... +40 °C / -4 ... +104 °F
Humidity
max. 95% r.H. (non condensing)
IP44
Safety rating
Dimensions
90x90x16mm /
3.55x3.55x0.63" (LxWxH)
This device is free of main-
Maintenance & Cleaning
tenance and may only be
cleaned with a dry cloth.
Installation & electrical connection
The installation of this device has to be carried out by a
qualified person. The device has to be fitted in accordance
with building regulations for electrical and fire safety. If the
device is not installed according to manufacturers
guidelines the protection of the device may be affected.
This folder is a part of the product!
For additional information,
declaration of confirmity, visit
loxone.com/help/intercom
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Intercom
Part No: 100484 (White)
Part No: 100485 (Anthracite)
