- Page 1 RIGrunner for model 4010S www.westmountainradio.com 1020 Spring City Drive Waukesha, WI 53186 262-522-6503 sales@westmountainradio.com ©2012 West Mountain Radio, All rights reserved. All trademarks are the property of their respective owners.
- Page 2 The RIGrunner is a simple device, with obvious function. Think of a RIGrunner as the 12 volt equivalent of a 120 VAC power panel in a house. There are some considerations to think about. Please read these instructions carefully before setting up your RIGrunner.
- Page 3 FUSES IS DANGEROUS AND VOIDS THE RIGRUNNER WARRANTY. Since the maximum available automotive fuse is 40 amps, the RIGrunner will be protected as long as any value ATC/ATO fuse is installed. Choose the correct fuse for your equipment. Standard ATC/ATO automotive blade fuses are used.
- Page 4 It should last indefinitely compared to a mechanical switch that suffers from arcing. The mechanical control switch in the RIGrunner carries none of the load. The control switch has three positions: “OFF”, “AUTO” and ALL ON”. In the “OFF” position only the switched outlets are switched off.
- Page 5 The RIGrunner is extensively RF bypassed and should minimize the possibility of this problem. In the case of an overvoltage condition during transmit, especially with a VHF high power...
- Page 6 RIGrunner Warranty The RIGrunner is warranted against failure due to defects in workmanship or materials for one year after the date of purchase from West Mountain Radio or an authorized dealer. If purchased from an authorized dealer it must be returned with a copy of the original sales receipt or proof of purchase.
- Page 7 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: 58305-1032...
