Summary of Contents for Detech EDS REACHER

  • Page 2: Assembling Your Detector

    ASSEMBLING YOUR DETECTOR 1. On the lower rod assembly, remove the mounting screw and thumb nut from the rod tip. 2. Insert the rod tip between the mounting ears of the search coil and align the holes of the rod tip and washers with those of the mounting ears. 3.
  • Page 3 ASSEMBLING YOUR DETECTOR Your detector is standardly equipped with 9X9" new SEF PRO coil. This coil has better sensitivity and depth, better pin-pointing than the existing DD coils, keeps perfect balance even in high temperature range. For getting acquainted with the detector’s operation we recommend you at first use this 9X9"...
  • Page 4: Normal Mode Of Operation

    NORMAL MODE OF OPERATION The detector is extremely intuitive and easy to operatе. It is designed to operate with high quality, stability, sensitivity and detection depth without the necessity of making manual ground adjustments to the different ground conditions. Turn the controls and switches to the red marked positions (Figure 3). Tone 1/tone 2 and freq 1/freq 2 do not have red markers, as they do not influence the normal...
  • Page 5: Discrimination Control

    DISCRIMINATION CONTROL The fully counterclockwise position of the disc. control is marked in red - nugget. In this position you won’t have any audio discrimination of ferrous objects, all metal objects in the ground will be indicated with one and the same audio signal.
  • Page 6: Other Controls

    OTHER CONTROLS The sens control is often thought of as a depth control and it is, but it can also be used to make the detector more stable if interference caused by ground mineralization or electromagnetic fields are experienced. If your detector is quite nervous, noisy, please, decrease the sensitivity rotating the sens.
  • Page 7 OTHER CONTROLS The next, very important control is the normal / heavy soil switch. As we already mentioned, for mass searching, and for maximum quality of operation and detection depth on the most soil types we would recommend operation in the normal mode.
  • Page 8 BEACH HUNTING For beach hunting we recommend the operation of the detector in its normal mode of operation. Lets start with the beach hunting on normal dry beaches. These beaches are easiest for searching, and allow the highest increase of the sensitivity level.
  • Page 9 In some trashy areas the smaller sized coil would be beneficial for target separation. - Metal Interference. The EDS REACHER picks up metals beneath the searchcoil, and if the metal objects are big - on the side of the search coil too.
  • Page 10 All the EDS REACHER search coils are light for their sizes, very well electrostatic shielded, resistant to shocks and shakes, perfectly balanced and waterproof. They are all compatible and interchangeable, easy to mount and require no special tools.
  • Page 11 BATTERIES Your detector is standardly powered by four 1.5V Alkaline batteries, size AA (R6), which allow you to use the detector for 20-30 hours. The time of use depends on how many signals your detector will locate and process and whether you use headphones.
  • Page 12: Specifications

    SPECIFICATIONS Operating Frequency ....Freq.1 - 13.89 kHz; Freq.2 - 13.74 kHz Audio Frequency ................570 Hz Weight (with batteries included)............1460 g Length (extended) ..............51"(1300 mm) (unextended).............. 41"(1050 mm) Standard Searchcoil ....SEF Pro... 9" X 9" (230mm X 230mm) Optional Searchcoils SEF Pro ..12"...
  • Page 13: Maintenance

    MAINTENANCE The EDS REACHER is a high quality electronic instrument. Though ruggedly constructed and designed to withstand the normal treasure hunting demands proper care is essential. Operate your detector as recommended in this instruction manual. Remove the batteries from the detector if you are not going to use it for extended period of time.
  • Page 14 AIR TEST RESULTS The table shows you the results of comparative air tests between your REACHER detector with the standard 9"X9" searchcoil and other VLF detectors of leading metal detectors manufacturers. Please, note that with the 9"X9" coil the REACHER significantly exceeds as sensitivity all the other tested detectors.
  • Page 15 REACHER...
  • Page 17 picture 1...
  • Page 18 D E T E C H L T D 7,Vassil Levski Str. 9 7 0 0 S h u m e n B U L G A R I A detechbg@gmail.bg tel: 00359 893 562 134...
