- Page 1 INSTALLATION AND SETUP MANUAL RR-GPS 18x LVC SOFTWARE | Version 1.0 www.luminator.com...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ............................3 OVERVIEW ..............................3 COMPONENTS ............................3 INSTRUCTIONS ............................4 CONNECTING THE DEVICE ......................... 4 INSTALLING THE FIRMWARE ........................5 3.2.1 DOWNLOAD ..............................5 3.2.2 INSTALL ..............................6 3.2.3 VERIFY ..............................17 Page 2 www.luminator.com... -
Page 3: Introduction
INTRODUCTION 1.1 OVERVIEW Luminator Technology Group’s RR-GPS18x is a hardware accessory for RoadRunner Recorders. The RR- GPS18x software enables connecting the Recorder to the GPS unit and utilizing all of the features of the GPS unit. This firmware update will optimize the unit’s performance and ensure all functions are working as intended. -
Page 4: Instructions
4. To keep the GPS connected to the power from the Recorder in a vehicle (Figure 4) a laptop can be used. FIGURE 2: RS232C PORT FIGURE 3: CONNECTING USB TO SERIAL ADAPTER TO DEVICE (WORKBENCH SETUP) Page 4 www.luminator.com... -
Page 5: Installing The Firmware
3.2 INSTALLING THE FIRMWARE 3.2.1 DOWNLOAD 1. Download the Firmware zip file from (registration required) www.luminator.com 2. Under the SERVICE menu, choose ACCESS SECURE CONTENT and sign in or request an account. 3. After signing in, click DOWNLOAD CENTER under the SERVICE tab 4. -
Page 6: Install
2. Copy the Garmin folder FIGURE 5: COPY FOLDER 3. Right click on your desktop and select Paste FIGURE 6: PASTE FOLDER 4. The contents of the folder are shown in Figure 7: FIGURE 7: FOLDER CONTENTS Page 6 www.luminator.com... - Page 7 Note: If you are experiencing issues locating the USB To SERIAL under PORTs (COM & LPT) you may need to download these drivers from the adapter’s manufacturer. After completion of the driver installation reboot the PC and proceed. Page 7 www.luminator.com...
- Page 8 (Up to COM12). To change this, right click in device manager where the device is located, in the menu click Properties. FIGURE 10: CHANGE COM PORT NUMBER 8. Go to the Port Settings tab FIGURE 11: PORT SETTINGS TAB 9. Click on the Advanced button FIGURE 12: ADVANCED BUTTON Page 8 www.luminator.com...
- Page 9 Right click on Application SNRSRXCFG_330.exe and select Properties. Then go to the Compatibility tab. Check the box for Compatibility mode. Have this set to Windows 8. Next, check the box to Run this program as an administrator. Then click OK. FIGURE 14: COMPATIBILITY MODE Page 9 www.luminator.com...
- Page 10 12. Launch the SNSRXCFG_330.exe program and Select GPS 18x PV/LVC. FIGURE 15: SNSRXCFG_330.EXE PROGRAM 13. Application will load initial default screen FIGURE 16: DEFAULT SCREEN Page 10 www.luminator.com...
- Page 11 15. Click the connect button or go to COMM>Connect. Will give a connection success message when properly connected to device. FIGURE 18: CONNECTION SUCCESSFUL 16. Once Connected click on the radio button in the tool bar for “Get config from GPS” or press F8 and click “Yes” to continue FIGURE 19: UPLOAD CONFIRMATION Page 11 www.luminator.com...
- Page 12 19. Once completed, “GPS CONFIGURATION” will have updated GPS positioning which indicates the hardware device is communicating properly. Note: “Selected Sentences” should be GPRMC(GPS) only. The items in red should be removed if present. FIGURE 22: GPRMC SETTING Page 12 www.luminator.com...
- Page 13 20. Remove the selected sentences that aren’t required — in this case GPGGA, GPGSA, GPGSV, and PRGMF. a. Click on CONFIG>NMEA Sentence Selections>Disable all the unneeded selected sentences above and press OK. b. Click CONFIG>Send configuration to GPS. This will only show GPRMC selected sentences when completed. FIGURE 23: REMOVING SENTENCE FORMATS Page 13 www.luminator.com...
- Page 14 FIGURE 24: CONFIGURATION SCREEN 21. Click on “Config” in the menu tool bar and then select “Update Software.” Click OK in the pop-up to continue. FIGURE 25: UPDATE SOFTWARE Page 14 www.luminator.com...
- Page 15 22. A new window will open; click the .RGN file that populates and select Open FIGURE 26: RGN FILE SELECTION 23. Click Updater and click open FIGURE 27: SELECT UPDATER Page 15 www.luminator.com...
- Page 16 24. Select the Serial Port that the USB device is under; in this case COM4 *Baud rate can be left alone. Click OK. FIGURE 28: SET COM PORT FIGURE 29: UPDATE IN PROGRESS NOTE: The process should take about 1-2 minutes. Once completed it will show a successful notification and close out. FIGURE 30: UPDATE SUCCESSFUL Page 16 www.luminator.com...
-
Page 17: Verify
3. Once connected to the networked Recorder, a live map view in RSM is visible. Right click on CAM 1 of the Recorder to confirm GPS is connected, and enable Google Maps and Speed Graph. This should now be up to date as the GPS plugged in. FIGURE 31: CORRECT GPS FUNCTION Page 17 www.luminator.com... - Page 18 12V supply if connectivity issues persist (e.g., failing to locate device). If the unit is being powered through the Recorder and not the 12V supply, power down the recorder. Please contact technical support at: 888-AVT-USA1 (425-483-7100) or by email: support@apollovideo.com for further information or assistance. Page 18 www.luminator.com...
