- Page 1 C5-2040CS18-38-2X User Manual for High Speed Laser 3D Sensors Rev. 1.1 AT - Automation Technology GmbH...
- Page 2 © 2018 Automation Technology GmbH All rights reserved. No part of this document shall be reproduced, stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise without consent in writing from the owners, AT-Automation Technology GmbH. Disclaimer While care has been exercised in the preparation of this document to ensure that it is fully correct and comprehensive, the owners assume no responsibility for errors or omissions.
-
Page 3: Table Of Contents
Table of Contents TABLE OF CONTENTS ........................1 C5-2040CS18-38-2X OVERVIEW ......................2 Introduction ................................2 C5-2040CS18-38-2X General Specifications ......................3 Model Overview with Measurement Specification ....................5 Mechanical Drawing ..............................6 Housing Type ................................ 6 Dimensions ................................7 Wire assignment for Laser ............................9 Description of LEDs .............................. -
Page 4: C5-2040Cs18-38-2X Overview
C5-2040CS18-38-2X Overview Introduction The C5-2040CS18-38-2X sensor is a revolutionary product of an intelligent high speed laser triangulation sensor of the C5-CS family. It is optimised for 3D profile measurement by means of laser triangulation technique. The 3D profile extraction is performed in the sensor by using high performance Field Programmable Gate Array processors. -
Page 5: C5-2040Cs18-38-2X General Specifications
0 °C to +50 °C (non-condensing) Output Data Interface Gigabit Ethernet (IEEE 802.3) GigE Vision with GenICam Communication Protocol Mechanical Interface Power Connector 17 pin, M12 connector Ethernet Connector 8 pin, A-coded M12 connector C5-2040CS18-38-2X Manual Rev. 1.1 3... - Page 6 Mechanical Stress Specification Vibration (sinusoidal each axis) 2 G, 20…500Hz IEC 60068-2-6 Shock (each axis) 15 G IEC 60068-2-27 Enclosure rating IP67 IEC 600529 C5-2040CS18-38-2X Manual Rev. 1.1 4...
-
Page 7: Model Overview With Measurement Specification
Nominal FOV Near FOV Far Working Lateral Height Points per Z-Range Housing Field Field Distance Resolution Resolution Profile Model Name Type [ mm ] [ µm ] [ pixels ] C5-2040CS18-38-2X 2048 Model 5 C5-2040CS18-38-2X Manual Rev. 1.1 5... -
Page 8: Mechanical Drawing
Mechanical Drawing Housing Type Model 5 C5-2040CS18-38-2X Manual Rev. 1.1 6... -
Page 9: Dimensions
Dimensions Model 5 All dimensions in mm C5-2040CS18-38-2X Manual Rev. 1.1 7... - Page 10 All dimensions in mm C5-2040CS18-38-2X Manual Rev. 1.1 8...
-
Page 11: Wire Assignment For Laser
Signal Name Description Pin No. 24V Power Supply 24V (<15W) N.C. Power Supply Ground Cable Pin Assignment Description Pin/Wire No. Wire Colour Signal Name 24V Power Supply Brown Vcc_Laser Laser Supply Ground Black n.c. Blue C5-2040CS18-38-2X Manual Rev. 1.1 9... -
Page 12: Description Of Leds
Off = No network cable connected Green On = Network connected After Network connected: Green On = CCP status connected Off = CCP status disconnected 2 (LSR) Red On = Laser is On Off = Laser is Off C5-2040CS18-38-2X Manual Rev. 1.1 10... -
Page 13: Slave
4 (LNK) Green On = Linkspeed 1 Gbit Amber On = Linkspeed 100 Mbit Off = Linkspeed 10 Mbit or wait for end of auto negotiation 5 (ACT) Green blink = Indication of network activity C5-2040CS18-38-2X Manual Rev. 1.1 11... -
Page 14: Service Information
In order to process your support inquiries immediately, we always need the serial number of the camera, the firmware version, the device version, the camera configuration file (*.cfg), a snapshot and a precise problem description. Product Inquiries and Price Quotations info@AutomationTechnology.de C5-2040CS18-38-2X Manual Rev. 1.1 12... -
Page 15: Warranty Conditions
Warranty Period The sensors warranty for the C5-CS series is 1-year starting from the date of purchase from AT – Automation Technology GmbH. Extended Warranty The warranty period can be extend to maximum 36 months. -
Page 16: Document Revision
Document Revision Rev. No. Date Modification 18.04.2017 First Draft 07.09.2018 Minor Corrections C5-2040CS18-38-2X Manual Rev. 1.1 14...
