- Page 1 Mini Land Planer Mini Skid Steer Loader Mini Track Loader Operator’s Manual Set-Up Assembly Maintenance Parts Information Read this Manual Before Use...
-
Page 2: Table Of Contents
Serial Number………….._____________ YOUR ATTACHMENTS DEALER ADDRESS: PHONE: CONTACT: NOTE: Erskine Attachments LLC reserves the right to make improvements in design or changes in specifications at any time without notice and without incurring any obligations to install them on units previously sold. -
Page 3: Safety
Indicates potentially Erskine Attachments LLC cannot anticipate every hazardous situation which, if not avoided, possible circumstance that might involve potential will result in death or serious injury. hazard. The safety messages found in this manual ... - Page 4 Do not modify equipment or add attachments that are not approved by Erskine Attachments LLC. Use adequate safety warning lights and devices as required by local regulations. Obey all local laws and regulations regarding machine operation on public property.
-
Page 5: Serial Number/Decal Location
SERIAL NUMBER AND DECAL LOCATIONS Serial Number Location: It is important to refer to the serial number of the attachment when making repairs or ordering parts. Early or later models (identification made by serial number) may use different parts, or it may be necessary to use different procedures in doing a specific operation. -
Page 6: Mounting Instructions
USER’S INSTRUCTIONS FOR MOUNTING THE MINI PLANER__ After uncrating the attachment, use the following procedure to mount the attachment to the loader. Coupler wedges or pins must extend through the holes in attachment. Levers must be fully down and locked. Failure to secure wedges or pins can allow attachment to come off and cause injury or death. -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS Always call before you dig. When you call, you will be directed to a location in your state/city for information about buried lines (electric, telephone, cable TV, water, sewer, gas, etc.). The Mini Planer is not designed to be operated on loaders with a Rated Operating Capacity (ROC) of more than 1000 pounds. - Page 8 OPERATING INSTRUCTIONS Using the Scarifier Teeth 1. The Mini Planer is designed such that the scarifier teeth are only engaged while travelling in reverse. When the scarifier teeth are engaged, they break up hard or compacted soil, while the cutting edges level the soil.
- Page 9 OPERATING INSTRUCTIONS Leveling the Ground 1. To level the ground, raise lift arms and tilt the attachment to the desired angle. 2. If operating while moving forward, tilt the attachment so there is more pressure on the rear cutting edge than there is on the front cutting edge If operating while moving in reverse, tilt the attachment so there is more pressure...
-
Page 10: Routine Maintenance
_____________________ROUTINE MAINTENANCE________________ Lower the Mini Planer so that it rests flat on the ground, set the parking brake, shut down the engine, and remove the key before leaving the operator’s station to perform service of any kind. It is the operator’s responsibility to make daily inspections of the loader and attachment for damage, loose bolts, fluid leaks, or anything else that could cause a potential service or safety problem. -
Page 11: Scarifier Removal/Installation
Scarifier Removal/ Installation Removal and Installation of Scarifier With the Mini Land Planer on flat ground remove the Locking Pin from the scarifier. 2. Loosen the (2) bolts from the center support plates and remove the plates, replacing the bolts into the plates for future use. - Page 12 Scarifier Removal/ Installation Removal and Installation of Scarifier Cont. 4. Safely lift the scarifier (approx. 40 lb) from the Mini Landplaner. 5. Loosen the (4) bolts from the end plates and remove the plates, replacing the bolts into the plates or future use. 6.
-
Page 13: Parts Information
PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NO. 400800 FRAME MINI LANDPLANER W/A 400801 SCARIFIER W/A SCARIFIER PKG 400803 400808 PLATE SCARIFIER MNT PNT(UNPNT 400820) SCARIFIER PKG 400803 400809 PLATE SCARIFIER RETAIN PNT(UNPNT 400821) SCARIFIER PKG 400803 400802 PIN 0.69 X 3.00 W/A Z SCARIFIER PKG 400803 102687 PIN HITCH 1/2 X 2-3/8... - Page 14 PARTS INFORMATION...
-
Page 15: General Specifications
GENERAL SPECIFICATIONS Model Mini Land Planer Weight / with Scarifier Option 225 pounds / 275 pounds 50.50” Overall Width 16.00” / 20.06” Overall Height / with Scarifier Down Scarifier Teeth 4.06” Scarifier Maximum Cutting Depth 8.50” Scarifier Teeth Spacing 43.00”... -
Page 16: Bolt Torque Information
BOLT TORQUE INFORMATION... -
Page 17: Notes
NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________... -
Page 18: Warranty
Erskine Attachments, LLC to improve its products whenever it is possible and practical to do so. Erskine Attachments, LLC reserves the right to make changes and or add improvements at any time without incurring any obligation to make such changes or add such improvements to products previously sold. - Page 19 P/N 421999 Date Printed: 3/4/2019 Printed in U.S.A. Erskine Attachments LLC...
