Garmin Edge 305 Owner's Manual

➊

Position the Heart Rate Monitor

1. Push one tab on the elastic strap through the slot in the
heart rate monitor.
2. Wet both sensors on the back of the heart rate monitor to
create a strong connection between your pulse and the
transmitter.
sensors
3. Place the heart rate monitor directly on your skin, just
below the breastplate. Wrap the strap around your chest
and attach the strap to the other side of the heart rate
monitor.
4. Tighten or loosen the strap as necessary so that it fits
snugly against your body.
For more information on using the heart rate monitor with your
GPS device, refer to your owner's manual.
➋
Configure Your GPS Device
1. Turn on your GPS device.
2. Bring it within range (3 meters) of the heart rate monitor.
3. Press mode to access the Main
Menu.
4. Go to the Accessories page. For
example, on the Edge 305, select
™
Settings > System > Accessories.
5. In the Heart Monitor field, select
Yes.
6. Make sure there are no other sensors
around you. Select Restart Scan.
Note: To set up custom data fields on your GPS device to display
heart rate data, refer to your owner's manual.
April 2006 190-00651-00 Rev. B
Example: Edge 305
Printed in Taiwan
