Summary of Contents for heimgard 16A
- Page 1 In-wall Switch...
-
Page 2: Device Overview
Device overview FRONT VIEW Switch input Zigbee In-Wall Switch Reset button LED Indicator Load output AC 100-240V power input... -
Page 3: Device Specifications
Device Specifications Output Output Size Input voltage voltage current (LxWxH) 100-240VAC 100-240VAC 16A max 45.5x45x20.3 mm... -
Page 4: Product Specifications
Product Specifications Compatible Load Types Load Symbol Load Type Maximum Load Remarks Due to variety of LED lamp designs, LED lamps with 1220W @ 230V maximum number of LED lamps is transformers 580W @ 110V further dependent on power factor result when connected to switch Maximum permitted number of 1220W @ 230V... - Page 5 Wiring Notes for the diagrams: L - terminal for live lead Zigbee In-Wall Switch N - terminal for neutral lead L1 - output terminals of the device (controlling connected light source) S - terminal for external switch NC - No Connection...
-
Page 6: Connecting To The Hub
These steps are to be followed after the switch has been properly installed and wired by a certified electrician. At the circuit breaker, turn off the power to the switch. Open the Heimgard app and follow the steps listed here to connect to your device Manage Devices... - Page 7 Turn the circuit breaker power on to your switch. It will automatically enter pairing mode. The LED indicator light on the switch will flash 2 times slowly to indicate pairing. When the LED indicator flashes 5 times and then remains on the device has been found in your app.
-
Page 8: Factory Reset
Factory Reset If your switch has previously been connected to a different Hub, you may need to perform a factory reset. Quickly press the reset button 5 times continuously. If you do not have access to the device, turn on and off the power supply 5 times from the either the curcuit breaker or light switch. - Page 9 The device that is connected to this switch will flash or turn on/off 3 times to indicate success- ful reset. You will have to reconfigure your device. Note: make sure your light bulb is functioning properly...
-
Page 10: Need Help
Need help? Website: heimgard.com/support Email: support@heimgard.com Facebook: facebook.com/heimgardnorge/ Telephone: +47 649 44 422 Visit heimgard.com for more information and tips on how to use. -
Page 11: Important Safety Information
Important safety information Read through these instructions and follow accordingly. Clean only with dry soft cloth. Household cleaners and solvents can damage the finish on your device. Do not install near any heat sources such as radiators, heat registers, stoves or other device that produce heat. Do not use this device near water. - Page 12 heimgard.com...
