MAN055 – REV. 0 DATE: 11.01.2011
SEMI-AUTOMATIC SELF-CLEANING FILTER WITH PRESSURE REDUCER
Changes reserved!
Acqua Brevetti 95 s.r.l.
DRAFT BY: U.T.
INSTALLATION AND OPERATING MANUAL
BravoFIL Plus
Semi-automatic
pressure reducer.
BravoFIL Plus
Fittings
¾"
1"
1"1/4
Read carefully this manual before use; keep
this manual near the filter.
PAG. 1 DI 9
self-cleaning
filter
with
Code
FT120
FT122
FT124
ENG
Advertisement
Table of Contents
Related Manuals for Acqua Brevetti BravoFIL Plus
Summary of Contents for Acqua Brevetti BravoFIL Plus
- Page 1 SEMI-AUTOMATIC SELF-CLEANING FILTER WITH PRESSURE REDUCER BravoFIL Plus Semi-automatic self-cleaning filter with pressure reducer. BravoFIL Plus Fittings Code ¾” FT120 1” FT122 1”1/4 FT124 Read carefully this manual before use; keep this manual near the filter. Changes reserved! Acqua Brevetti 95 s.r.l.
- Page 2 MAN055 – REV. 0 DATE: 11.01.2011 DRAFT BY: U.T. PAG. 2 DI 9 DIMENSIONS Filter Code FT120 FT122 FT124 The dimensions are in mm Document Revision Revision notes Date MAN055 Emission 11.01.11 Acqua Brevetti 95 s.r.l.
- Page 3 2.4 DEALERS AND AUTHORIZED CUSTOMER SERVICE ACQUA BREVETTI 95 S.R.L. The semiautomatic cleaning filter can be purchased exclusively from authorized dealers. The maintenance of the semi- automatic cleaning filter could be done only by Acqua Brevetti 95 s.r.l. authorized customer service, identified by the following logo: 2.5 STANDARD PACKAGING...
-
Page 4: Filter Installation
4.0 GENERAL INSTALLATION FLOW SHEET Legenda 1. Cold water inlet; 2. Water flow meter; 3. Back flow prevention device; 4. Zone valve; 5. Sampling tap; 6. By-pass valve; 7. BravoFIL filter; 8. Cold water outlet; 9. Discharge. Acqua Brevetti 95 s.r.l. -
Page 5: General Features
5.1.1. OVERVIEW BravoFIL Plus is a robust and compact filter used for filtering water for civil and industrial uses. It fits into narrow spaces. During the filtration phase, water enters the filter and flows down through the filtering cartridge from the exterior to the interior and comes out clear. - Page 6 To obtain an optimal filteration efficency it is advisable to clean the filter with at least 2 bar of counter pressure down stream the filter. To obtain this condition it is possible to use the closing valve placed downstream the filter. Acqua Brevetti 95 s.r.l.
- Page 7 Replace the discharge valve in the filter bowl Screw the bowl on the filter head. 2.1. 2.2. Screw the closing brass nut Discharge valve Discharge valve Insert the discharge green conveyor and place the pin. opened position closed position Acqua Brevetti 95 s.r.l.
-
Page 8: Troubleshooting
Check the filter which is probably not properly working. Water leakage from the upper Pressure reducer membrane Replace the membrane. part of the pressure reducer damaged Attention This kind of operations must be done by qualified technical personnel Acqua Brevetti 95 s.r.l. -
Page 9: Declaration Of Conformity
m to 150 m – Requirements for performances, safety and testing Acqua Brevetti 95 S.r.l. operates with a Quality System certified according to Standard UNI-EN ISO 9001:2000, with certificate N°50 100 7368 drafted by TüV Italia S.r.l. Mestrino, 07/02/2008 Acqua Brevetti 95 Srl 7.0 ENVIRONMENTAL PROTECTION INFORMATION...
