MoticEasyScan Pro 6N
Instruction Manual
Complete reading of this manual
before opeartion is required.
If the equipment is used in a manner
not specified by the manufacturer,
the protection provided by the
Note
equipment may be impaired.
Changes or modifications not
expressly approved by the party
responsible for compliance could
void your authority to operate the
equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MoticEasyScan Pro 6N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Motic MoticEasyScan Pro 6N

Summary of Contents for Motic MoticEasyScan Pro 6N

  • Page 1 MoticEasyScan Pro 6N Instruction Manual Complete reading of this manual before opeartion is required. If the equipment is used in a manner not specified by the manufacturer, the protection provided by the Note equipment may be impaired. Changes or modifications not...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Device Safety Instructions General Safety Tip Safety Sign Device Safety and EMC Warranty Description General Description Product Application Range 2.1.1 Intend Use System Overview 2.2.1 System Diagram 2.2.2 System Installation 2.2.3 System Connection Diagram 2.2.4 Port Description 2.2.4.1 Device Hosting Ports Description 2.2.4.2 Computer Ports Description 2.2.5 System Connection Operation...
  • Page 3 User Interface Slide Scanning 3.4.1 Slide scanning — operation interface 3.4.2 Slide Scanning — Advanced Mode Interface Digital Slide Browsing NFC Function Operation Guidance Cautions Operation Instruction Maintenance and Troubleshooting Care and Maintenance System Calibration 5.2.1 Calibration 5.2.1.1 Import Calibration File 5.2.1.2 Auto Calibration 5.2.1.3 Manual Calibration Trouble Shooting...

  • Page 4: Device Safety Instructions

    1. DEVICE SAFETY INSTRUCTIONS 1.1 General Safety Tip Before using the device, make sure to follow the instructions given in the Manual. For installation instructions, please consult Chapter 2 and 3 of this Manual. 1.2 Safety Sign The following signs are shown on the system. Every user must make sure to understand the definition of the safety signs to always operate the device the most secure way.

  • Page 5: Device Safety And Emc

    Please make sure the EVA foam is taken out before starting any operation!! Detail please checks the manual. For damaged, missing or unreadable labels, please contact Motic Group Corporation for replacement before continue operation. 1.3 Device Safety and EMC ●...

  • Page 6: Warranty Description

    1.4 Warranty Description MoticEasyScan Digital Slide Scanning System and its components are only allowed to be operated within techniques and processes described in this operation manual. Please noted: USB 3.0 port in MoticEasyScan shall only be connected to certified computer according to IEC/ANSI/UL 60950-1 & 62368-1.

  • Page 7: General Description

    1 or 1 to 6 pieces of glass slide in the tray at the time. Rapid high quality digital slide scanning can be achieved with Motic digital slide scanning software Easyscanner. It is applicable for scanning, digital storage, transferring and browsing of histopathology slide, cytology and biology slides etc.

  • Page 8: System Installation

    2.2.2 System Installation Before installation, please be familiar with following parts. USB 3.0 cable Power Supply Cable (Fig. 2) 2.2.3 System Connection Diagram (Fig. 3)

  • Page 9: Port Description

    2.2.4.1 Device Hosting Ports Description ● MoticEasyScan Pro 6N Connect the USB 3.0 of the MoticEasyScan Pro 6N to the USB 3.0 of your computer (the USB 3.0 port is usually blue or next to it, which Marked “SS”.) (Fig. 4)

  • Page 10: Computer Ports Description

    USB port of host computer should be USB3.0 port, which is signed with SS or marked as blue color. Computer Port Diagram (Fig. 5) 2.2.5 System Connection Operation *** Please make sure the EVA foam (Fig. 6), which is inside the MoticEasyScan Pro 6N is taken out before starting any operation (Fig. 6)
  • Page 11 Then slide the front panel out in horizontal direction from the device. (Fig. 7b) ● Cut the nylon cable tie ● Remove the EVA foam carefully. (Fig. 7b) ● Slot the front panel and the U shape panel back into the MoticEasyScan Pro 6N and lock the locking screw. (Fig. 7a) (Fig. 7b)

  • Page 12: Slide Tray

    ● MoticEasyScan Pro 6N Connection Please make sure that all power is switch off before connecting. Take reference of system connection diagram (Fig. 4), follow the steps below for connection. ■ Plug one end of USB3.0 line to USB port of scanner and connect the other end to USB3.0 port of computer.
  • Page 13 Note: ① ② Ensure the backside of clip Fig. 8b- and Fig. 8b- are pressed on the top of the slide. Try not to touch the cover glass on the slide during the whole process. (Fig. 9a) (Fig. 9b) (Fig. 9c)

  • Page 14: Slide Unloading Procedure

    2.3.1.2 Slide unloading Procedure: Hold the slide with index finger and thumb, unload the slide by pushing the slide towards the ① direction of clip Fig.8b- until the other end of the slide can be lifted (Fig. 10a) Lift the slide upward to move out of the slide position (Fig. 10b) Note: Try not to touch the cover glass on the slide during the whole process.

  • Page 15: Slide Tray Loading Procedure

    2.3.2 Slide tray Loading Procedure: Open the right flip cover, load the slide tray with the direction shown in the figure, and make sure the top surface of slide-tray fits below marked line (Fig. 11a). After inserting the slide-tray, ensure the triangle arrow of positioning slot “GO” points to the dot (Fig.

  • Page 16: Software Installations And Instructions

    3. SOFTWARE INSTALLATIONS AND INSTRUCTIONS 3.1 Software Installation Double-click Setup.exe file in the installation program; Select installation language and click on the “Next” button; Then click “Next” button;...
  • Page 17 Select installation path and click “Next” button; Select the database installation path and click the “next” button; Click “Install” button to proceed installation and display installation process;...
  • Page 18 When installation is completed, click “Finish” button to complete software installation...

  • Page 19: Driver Installation

    3.2 Driver Installation 3.2.1 Driver Installation for Main camera Find the camera in the “Device manager”, then click “Update Driver Software”. Click “Browse my computer for driver software”. Click “Browse”, select Drivers\PointGrey in the folder, and click “Next” button.
  • Page 20 The files are being copied to your computer. When the installation is completed, close the window in the following figure to complete the driver installation. To ensure the proper work of your device, please restart your computer.

  • Page 21: Driver Installation For Focusing Camera

    “USB3.0 Camera” shows under the PC “Device manager”, then click “Update Driver Software”. Click “Browse my computer for driver software”. Click “Browse”, select the installation package of Motic EasyScanner, then find “Motic USB3.0 Camera” from “Drivers” folder, and click “Next” button.
  • Page 22 Click “Install” button. The files are being copied to your computer. Click “Close” button. To ensure the proper work of your device, please restart your computer...

  • Page 23: Driver Installation For Macro Camera

    3.2.3 Driver Installation for Macro camera “Motic USB3.0” shows under the PC “Device manager”, then click “Update Driver Software”. Click “Browse my computer for driver software” Click “Browse”, select the installation package of Motic EasyScanner, then find “Motic USB3.0 Camera” from “Drivers” folder, and click “Next” button.
  • Page 24 Click “Install” button. The files are being copied to your computer. Click “Close” button. To ensure the proper work of your device, please restart your computer...

  • Page 25: Driver Installation For Moxa Usb Serial Port Driver

    3.2.4 Driver Installation for MOXA USB Serial Port driver “U Port 1110 driver” shows under the PC “Device manager”, then click “Update Driver Software”. Click “Browse my computer for driver software” Click “Browse”, select Drivers\Moxa in the installation package, and click “Next” button.
  • Page 26 The files are being copied to your computer. Click “Close” button. To ensure the proper work of your device, please restart your computer. “MOXA USB Serial Port” shows under the PC “Device manager”, then click “Update Driver Software”.
  • Page 27 Click “Browse my computer for driver software” Click “Browse”, select Drivers\Moxa in the installation package, and click “Next” button. The files are being copied to your computer.

  • Page 28: User Interface

    Click “Close” button. To ensure the proper work of your device, please restart your computer 3.3 User Interface Double-click the software icon on the desktop to run the software, and the following interface will display. This is simplified operation interface, software initial status “Scan” button is in grey. After loading the slide tray, “Scan”...
  • Page 29 Slide Folder: Set up batch slide scanning saving route Preview: The macro image of clicking the slide for batch scanning. Scan: Click the slide for batch scanning Unload Tray: slide tray will move to the left side (the dot on the slide tray will be pointed to the triangle point of FINISH of left side positioning slot), then open the left flip cover and take the slide tray out.
  • Page 30 The advanced mode interface consists of a title bar, menu bar, tool bar, observation window, status bar, and each Panel (such as video tuning, digital chips scanning and device control window). User interface applies floating/ fixed window design, the user can customize the window layout, all windows can be set as floating, fixed or hidden type.

  • Page 31: Slide Scanning

    3.4 Slide Scanning 3.4.1 Slide scanning — operation interface Operation interface can realize simplified operation, simplified setting and fast batch scanning. Operation interface is the main interface of the scanning software. It provides essentially One-Click-Operation, but allows simple customization steps to operate Scanner. The software provides basic default settings, but user can also manually set-up slide-tray storage path, scanned magnification and scan mode if needed.
  • Page 32 Create New Slide In the tool bar, click and a window will be popped up, type in corresponding slide name and description, select encode method and slide storage path, click “confirm” button.
  • Page 33 Create Focus Model Focus model establishment includes auto model and manual model. If selecting “Auto Modeling”, please follow below procedure. ● Move the slide to ensure the area with tissue is in the middle of the field. Focus the slide until a sharp tissue image is acquired in the field.

  • Page 34: Digital Slide Browsing

    3.5 Digital Slide Browsing In the main window of the software setup interface, select the slide library tab to display the list of slide scanning records. The user can open the digital slide browser by double clicking the section of the slide list column.

  • Page 35: Operation Guidance

    MoticEasyScan Pro 6N, a new slide tray can be loaded after loading When software exits normally, the slide tray will be exit to the left side of the MoticEasyScan Pro 6N. The scanned slide tray can be removed by opening left cover flip and remove the slide tray.

  • Page 36: Maintenance And Troubleshooting

    5. MAINTENANCE AND TROUBLESHOOTING 5.1 Care and Maintenance Keep the slide tray clean (especially the backside of the slide tray) to prevent contamination and deformed during operation. Keep scanning guiding rod clean and avoid foreign objects attaching to the top which would result to uneven placement of slide affecting the scanning results.
  • Page 37 Note: Generally backup is recommended even the MoticEasyScan Pro 6N is in a good working condition or once the calibration is completed. Go to “System Calibration”, click ‘Import’ button and select the backup calibration file.

  • Page 38: Auto Calibration

    5.2.1.2 Auto Calibration This is an intuitive automatic calibration procedure which provides simple and quick operation. It is only required when changing the objective or poor scanned images. Auto Calibration Settings Follow the wizard; select a blank spot then a tissue spot and the entire tissue region in the map. Click the Auto Calibrate as shown in the following figure, it will automatic complete the System Calibration, Macro Calibration and Focus Calibration.

  • Page 39: Manual Calibration

    5.2.1.3 Manual Calibration It is required when changing the hardware especially replacing the camera or system fail to auto calibrate. System Calibration ● Video Calibrate: remove the slide first, and click the Calibrate button, the system will automatically execute the "Exposure", "Background Balance", "White Balance". ●...
  • Page 40 ● Camera Angle Camera angle offset calibration is to calibrate the camera angle offsets against the instrument axis, this ensures the image stitching. Camera Angle: display calibration results of camera angle Calibrate: start to perform calibration operation (Please read the calibration conditions before calibration).
  • Page 41 ● Click “Prepare Label Exposure” on the calibration wizard window, then system will automatically move to slide label section. ● Manually adjust the exposure bar and ensure the brightness of label is suitable. ● Click Complete Macro Image Settings. ● Select an area which can cover whole tissue by dragging a rectangle over it with the mouse.
  • Page 42 (Fig. B) (Fig. C)
  • Page 43 Calibration: Please follow the steps 10 and 11 (Fig. B) (Fig. D) ● Select an area which can cover whole tissue by dragging a rectangle over it with the mouse. Then click “Scan Map” button. After scanning map completed, click “Calibrate” button to complete calibration. ●...
  • Page 44 c. Focus Camera Calibration It is mainly to calibrate the video parameters of focus camera and the correspondence with z axis. Please do as below to perform Camera Auto Focus Calibration (refer to the detailed instructions): ● Make sure a slide with rich texture has been placed on the slide magazine (such as slide1), then load this slide.

  • Page 45: Trouble Shooting

    1.Check USB3.0 cable is properly connect 2. Check if power of EasyScanner software can’t be Can’t detect the MoticEasyScan MoticEasyScan Pro 6N is switch opened Pro 6N 3. Switch off the MoticEasyScan Pro 6N and restart it Switch off the MoticEasyScan No image display Can’t detect the camera...

  • Page 46: Appendix

    6. APPENDIX 6.1 Specifications Model MoticEasyScan Pro 6N Slide Capacity 6-slide tray can load 1~6 slides Slide Tray Dimension 210 x 100 x5.8mm Length: 75-76mm Slide Dimension Width: 25-26mm Thickness: 0.9-1.2mm X axis parameter X maximum scanning range (max) 25mm...

  • Page 47: Storage Environment

    Lift equipment base plate on both sides respectively, during lifting and handling process, need to keep balance of device to prevent rollover. ** Attention: MoticEasyScan Pro 6N net weight: approximately 16KG. ● If you need to pack MoticEasyScan Pro 6N for long distance transportation, please contact Motic or the Motic Distributor. (Fig. 13)

  • Page 48: Replacement Of Parts & Accessories

    Please do not put non-relevant stuff on the device ● When replacing the fuse, please refer to the label parameter “FUSE: 250V T2.5AL” near the equipment power socket. ● LED lamp life time is 25000 hrs, please contact Motic authorized distributor if there is any failures.

  • Page 49: Lens Cleaning

    When the device is not used, use vinyl dust cover to cover the device and put it in the low humidity area to avoid mold. Proper operation of the instrument can pro long the instrument life span and reliability. For maintenance services, please contact your nearest Motic authorized distributor;...
  • Page 50 Fax: 86-0592-562 7855 © 2007-2020 Motic China Group Co., Ltd. All rights reserved. Motic is a registered trademark and service mark of Motic China Group Co., Ltd. Microsoft Windows logo is a registered trademark of Microsoft Corporation. All other trademarks are the property of their respective owners.
