- Page 3 All our products are designed and manufactured right here in Australia, allowing us to have better lead times and better quality control than companies manufacturing overseas. By supporting us you’re supporting to grow the Australian economy and our brand. We do not design our bars to look the same across the vehicle range. We fully develop our own product to individually suit each vehicle.
- Page 4 ● Take a few moments to read instructions thoroughly before beginning work. ● In the event of damage to any bar component please contact Uneek 4x4 in regards to repair/replacement of components. ● Do not use this product for any vehicle make or model other than that specified on these instructions.
- Page 6 ● Remove original side steps and brackets. ● Bend nut plate stem and insert through the bottom hole of the forward cross member. Ensure the protrudes through the upper opening in the chassis rail and the nut is aligned to accept a bolt through the bottom hole. ●...
- Page 7 M6-9Nm ● Position the slider against the chassis rail and loosely fit the rear bracket. Note: It is advisable to remove the fuel tank cover on the right-hand side of the vehicle for easier sight to mounting brackets. Note: Assistance from another person and or hydraulic jack will be required to lift sliders into position.
- Page 8 M12-77Nm ● Align mount holes in front bracket to the corresponding holes in the chassis. ● Fit internal nut plates into chassis, bending plate arms as needed and secure. (nut plate facing towards the ground should already be in place from step 2) ●...
- Page 9 Note: 04-0276 was placed in chassis rail in step 2. Tip: A large F clamp or G clamp is useful to hold inner mounts hard up against chassis rails whilst aligning the slider. M12-77Nm Adjust sliders into position and secure all mounting bolts to the vehicle...
- Page 10 Repeat steps 4-6 for left hand side of vehicle Step back and admire your work. Awesome job!
- Page 11 Revised: 29/11/2019 1800 806 952 www.uneek4x4.com.au 20 Gateway Drive, Carrum Downs, VIC, 3201...
