Summary of Contents for UNEEK GQ-FB-C-ASMO
- Page 3 Uneek 4x4 back itself as Australias leading steel bull bar manufacturer. This is why we provide you with the best steel bar warranty in Australia - 5 years.
- Page 4 • Take a few moments to read instructions thoroughly before beginning work. • In the event of damage to any bar component please contact Uneek 4x4 in regards to repair/replacement of components. • Do not use this product for any vehicle make or model other than that specified on these instructions.
- Page 6 Remove bumper. Keep original fasteners together. Fit LHS chassis bracket with nut plate inside chassis rails. Push the bracket back as far as it can go towards the car and torque up M12 x 40 bolts with spring washers and flat washers. Fit LED winch light to winch cradle if purchased.
- Page 7 With the help of another person lift bull bar onto vehicle and secure using M12 x 40 bolts, spring washers and large flat washers. The top 3 mounting holes are for vehicles with no body lift. If your Patrol has a 2” body lift, lift the bar higher and use the bottom 3 mounting hole Standard height mounting holes shown to the right.
- Page 8 Secure winch to cradle using bolts and fairlead supplied with winch. NOTE: If using a low mount winch ensure the clutch handle is accessed easily. Refer to winch manual in regards to gearbox rotation. Fit your number plate to the front with supplied M6 bolts washers and flange nuts.
- Page 10 Revised: 01/08/2019 1800 806 952 www.uneek4x4.com.au 20 Gateway Drive, Carrum Downs, VIC, 3201...
