GTCO CalComp 2024 Specifications

F E A T U R E S
Industry's highest resolution and accuracy
Large Format Digitizers
Resolution up to 12,700 lines per inch
■
Accuracy levels offered:
■
±0.010", ±0.005", ±0.002"
Graphic Tablets
Resolution up to 2,540 lines per inch
■
Accuracy up to ±0.010 inches
■
Choice of pointing devices
Cordless or corded 4 or 16-button cursor
■
Cordless or corded click tip pen with two side buttons
■
Cordless light touch pen with two side buttons
■
Cordless pressure pen with two side buttons
■
Illuminated 16-button cursor with high-accuracy digitizers
■
Convenience features
Easy-to-install software
■
Powered via USB connection which simplifies setup
■
Integrated USB and RS-232 serial connections
■
(RS-232 Serial requires optional power supply)
Software drivers
Wide range of compatibility
■
Programmable macros (RS-232 only)
■
L A R G E - F O R M A T
& G R A P H I C
Designed for demanding
CAD, GIS, engineering, textile
and construction estimating
applications, the DrawingBoard
VI series is the professional's
choice in large-format digitizers
and graphic tablets. DrawingBoard VI systems now
feature integrated USB and RS-232 serial connections.
When connected via USB no power supply is required
simplifying setup and operation.
DrawingBoard VI digitizers utilize the same Advanced
Function Technology that has set the world standard for
performance. Internally, these high performance tools are
engineered with a state-of-the-art positioning grid to
ensure reliability, performance and quality. Multiple
accuracy versions are available to match specific system
requirements and an integrated mounting channel
allows accessories, such as a pen tray, to be easily and
quickly mounted.
DrawingBoard VI digitizers also work with a variety
of cursors and stylus pens. Each pointing device offers
a number of programmable buttons. By assigning
specific program functions to these
buttons, you'll increase efficiency
and improve production times.
Drawing Board VI small-for-
mat digitizers feature a recessed menu area, and a clear
overlay that holds templates and menus in place.
When used with a menu, these tablets significantly
enhance user productivity by consolidating multiple
mouse selections into a single point-and-click action.
DrawingBoard VI tablets
and digitizers offer unparalleled
features and per formance no
matter what your application.
D I G I T I Z E R S
T A B L E T S
