- Page 1 NCE883MLBT USER MANUAL nce.com.au RV AUDIO SYSTEM Single DIN with Detachable panel Featuring AM/FM, USB, SD, BT, MP3 Player Remote Control Connect with USB, SD, Bluetooth, 3.5mm AUX and Rear RCA AUX BEFORE OPERATING, PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY.
- Page 2 Table of Contents Table of Contents Table of Contents Safety information/ Remote Control Panel Control Electrical Connections Installation Guide Troubleshooting Specifications...
-
Page 3: Remote Control
- The NCE883MLBT contains no user repairable parts. Please do not attampt to repair this unit yourself, use only reputable service agent. - Some File Types may not be supported. If you have any troubles with playback, please refer to the troubleshooting page in this instruction manual. - Page 4 1. POWER/MODE In power off mode press to turn the unit on, long press to turn the unit off. With the unit on, press to move through the various modes, Radio, USB, SD, AUX 1, AUX 2, BT. Note that USB, SD will only display if the media device is present / inserted. 2.
-
Page 5: Volume Knob
4. Panel detach Press to detach the front panel. 5. Band In radio mode press to move through the radio bands, F1(FM1), F2(FM2), F3(FM3), A1(AM1) A2(AM2) in a cycle sequence. 6. Channel + In radio mode push to move up through the preset radio stations. In SD/MMC and USB mode press to move forward through folders. -
Page 6: Programming Clock
Programming Clock In radio mode press and hold the Volume (8) button until clock is displayed let go and long press again until the hour starts to flash, use the Volume (8) knob clockwise and anticlockwise to adjust, short press the volume (8) button again to make the minutes flash, use Volume (8) clockwise and anticlockwise to adjust minutes long press volume (8) button when complete. - Page 7 Installation Procedures First complete the electrical connections and then check for correctness. Installation Opening 53mm MOUNTING SLEEVE 182mm This unit can be installed in any Cavity having an opening as shown above. We recomend the panel thickness should be a Minimum of 6mm and a Maximum of 25mm in order to support the unit.
- Page 8 If you suspect something is wrong, immediately switch power o . Do not use the unit in abnormal conditions, for example without sound, or with smoke or foul smell, this could cause re or electric shock. Immediately remove and call the place where you purchased it. Never try to repair the unit yourself because it is dangerous to do so or you may void your product warranty.
-
Page 9: Specifications
Specifications General Power supply: 12V DC Maximum power output: 50W X 4CH Speaker impedance: 4 - 8 Ohm Unit Dimensions(WxHxD): 178 x 50 x 130 mm Weight: 0.7 kg Fuse: 10 Amp Remote Control Battery: CR2025 3V Frequency Range : 87.5 MHz - 108.0MHz Channel step: 100 KHz... - Page 10 About our policy At NCE we want our customers to be completely satisfied with their purchase. We therefore recommend that you read be familiar with our Repair, Return and Refund Policy and our NCE General Terms and Conditions of Trade.
- Page 11 This Return, Repair and Refund Policy is applicable to purchases made from NCE Pty Ltd. *Estimated resolution days may vary to circumstances beyond ours/ or our suppliers control. To receive a copy of NCE’s full Terms and Conditions please contact our Head Office (03) 9308 7444 or visit www.nce.com.au/terms-and-conditions...
- Page 12 DISTRIBUTED BY NCE : 34-48 Stanley Drive, Somerton, Vic 3062 Tel: 1300 366 024 Email: sales@nce.com.au Web: nce.com.au MADE IN CHINA...
