OWNER'S MANUAL
CONTENTS:
Page 1 Press Specifications
4 Ram Cylinder Assembly
and Pump Assembly
5 Operating Instructions,
Preventative Maintenance
and Inspection
7 Troubleshooting and
ASME PASE-2014
Ram
Ram
Diameter
Travel
2-1/4"
6-3/8"
AE30TM
TM
PRESS SPECIFICATIONS
Throat
Throat
Height Min.
Height Max.
6-1/4"
42-1/2"
Throat
Bed
Width
Adjustments
28"
10 @ 4-1/2" apart
MANUAL SHOP PRESS
Bed Width
Base
(Between Rails)
Depth
7-1/4"
29-7/8"
37-7/8"
© Copyright 2015, AmerEquip™
AE30TM
30 TON
Base
Overall
Width
Height
70-1/2"
3/19/15
Advertisement
Table of Contents
Related Manuals for AmerEquip AE30TM
Summary of Contents for AmerEquip AE30TM
- Page 1 Throat Throat Throat Bed Width Base Base Overall Diameter Travel Height Min. Height Max. Width Adjustments (Between Rails) Depth Width Height 2-1/4" 6-3/8" 6-1/4" 42-1/2" 28" 10 @ 4-1/2" apart 7-1/4" 29-7/8" 37-7/8" 70-1/2" © Copyright 2015, AmerEquip™ AE30TM 3/19/15...
- Page 2 If the manual or product labels are lost or not legible, contact AmerEquip™ for replacements. If the operator is not fluent in English, the product and safety instructions shall be read to and discussed with the operator in the operator's native language by the purchaser/owner or his designee, making sure that the operator comprehends its contents.
- Page 3 AE30TM 30 TON MANUAL SHOP PRESS Equipping technicians with heavy-duty products WARNiNg iNSTRUCTiONS (CONTiNUED) CONSEQUENCES OF NOT AVOIDING HAZARDOUS SITUATIONS WARNING Failure to read this manual completely and thoroughly, failure to understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS, MAINTENANCE INSTRUCTIONS and comply with them, and failure to comply with the METHODS TO AVOID HAZARDOUS SITUATIONS could cause accidents resulting in serious or fatal personal injury and/or property damage.
- Page 4 AE30TM 30 TON MANUAL SHOP PRESS Equipping technicians with heavy-duty products RAM CYLINDER ASSEMBLY AND PUMP ASSEMBLY Plastic Washer Ram Cylinder Assembly Pump Assembly P6 P5 P3 P4 P5 P7 P8 P9 P10 P11 P12 P14 P15 P16 Allen Socket...
- Page 5 AmerEquip™ customer service. NEVER USE ALCOHOL, HYDRAULIC BRAKE FLUID OR TRANSMISSION FLUID IN THE HYDRAULIC SYSTEM. Use Chevron Hydraulic Oil AW ISO 32, Unocal Unax AW 150, or hydraulic jack oil. Every press owner is resposible for keeping press labels and owner's manual readable. Contact AmerEquip™ for replacement labels and manual if unreadable. INSPECTION Visual inspection of the shop press should be made before each use of the press, checking for damaged, loose or missing parts.
- Page 6 AE30TM 30 TON MANUAL SHOP PRESS Equipping technicians with heavy-duty products REPLACEMENT PARTS LIST Gauge (4) Hydraulic Hose Cylinder Ram Assembly Complete (1) Pump Assembly Winch (5) Complete (2) Head Plate Cylinder Support Ring Pump Handle (3) Moveable Bolster / Press Bed...
- Page 7 This product carries a TWO-YEAR warranty. During this warranty period, AmerEquip™ will repair or replace at our option any part or unit which proves to be defective in material or workmanship.
