Rossmax Neb Tester Instruction Manual

Specifications
Power source
Operating temperature
Storage temperature
scale
Air flow
accuracy
scale
Pressure
accuracy
Weight
Dimension
Cautions and maintenance
1. This device should be used with nebulizer only.
2. Place the device and nebulizer on a flat, horizontal surface while in use.
3. The device must be in a vertical position while in use.
4. Turn the regulator slowly to avoid possible damage.
5. Do not completely unscrew regulator stem.
6. Do not attempt to disassemble the device.
7. Avoid excessive vibration, physical impact and dropping.
8. Do not store the device in direct sunlight, high temperature or humidity.
9. Keep the device away from static electricity.
10. For the first use, open the rubber vent-plug on the back side of pressure gauge and
then close it in order to balance the pressure after the transportation.
Note: Do not open the rubber vent-plug when the device is in a vertical position to avoid
leakages of oil material from the pressure gauge.
Manufacturer: Rossmax International Ltd.,
12F., No. 189, Kang Chien Rd., Taipei, 114, Taiwan
www.rossmax.com
No need
0 ~ 54ºC
- 10 ~ 60ºC
1 ~ 10 L/min
± 4% of full scale
0 ~ 60 PSI
± 2% of full scale
1000 g
128 (L)*120(W)*158 (H) mm
Portable Testing Device
for Nebulizer
Neb Tester
Model:
Instruction Manual
www.rossmax.com
