- Page 1 LINK INSTALLATION MANUAL LK-CHRG08R DODGE CARAVAN | CHRYSLER TOWN & COUNTRY 2008 & up PASSENGER SIDE FRONT...
- Page 2 LK-CHRG08R-AB Air Bag LINK Kit -Right- LK760B 44" Vinyl Cover -Black- EW-CK-00 12V Power Supply Wiring Kit LK-UNI-650 Manual Backup Tool Kit PART NUMBER LK-CHRG08R DESCRIPTION 1 of 4 LINK Dodge Caravan 2008 & Up -Right- |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 3 Nylon Spacer id .317" od .500" SN 654-007 Nylon Spacer id .375" od .625" SN 681-129 Wave Disc Spring 0.325 id x 0.546 od x 0.007 thickness PART NUMBER LK-CHRG08R DESCRIPTION 2 of 4 LINK Dodge Caravan 2008 & Up -Right- |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 4 Trim Panel Clip Ø1/4'' x 3/4'' Black PRD 333-107 Nylon Insert Locknut 5/16-18 PRD 339-136P Socket Shoulder Screw Zinc Plated 3/8 x 1/2 x 5/16-18 THD PART NUMBER LK-CHRG08R DESCRIPTION 3 of 4 LINK Dodge Caravan 2008 & Up -Right- |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 5 PRD 332-164P Socket Head Cap Screw Zinc Plated 3/8-16 x 7/8 PRD 332-166P Socket Head Cap Screw Zinc Plated 3/8-16 x 1 1/4 PART NUMBER LK-CHRG08R DESCRIPTION 4 of 4 LINK Dodge Caravan 2008 & Up -Right- |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 6 OEM shrouds must be trimmed. Seat adjustments|FRONT: OEM |BACK: OEM Mid-row seat (Stow ‘n go) immediately behind LINK cannot be stowed. OEM wire harness must be cut and extended under seat. OEM wire harness must be cut and extended under seat.
- Page 7 The wiring must be extended 80 inches. This extension is placed near the seat connectors that are under the seat. The extension (80 inches) then passes under the LINK and loops around the back of the OEM seat – allowing the seat and the LINK to travel in and out of the vehicle.
- Page 8 BEFORE STARTING THE INSTALATION, PLEASE NOTE: If the LINK is being installed with a SPEEDY LIFT install the floor adapter brackets for the SPEEDY LIFT first. Remove the OEM seat and place it on a workbench or table. To do this, remove the plastic shroud and unbolt the seatbelt.
- Page 9 3. Unbolt the seat back from the seat base. Disconnect the wire harness between the seat cushion and the seat back. Unclip the upholstery to gain access to the harness. LINK Dodge Caravan|Chrysler Town & Country 2008 & up|Passenger FRONT – p.4...
- Page 10 5. Remove the seat base from the seat pan. The seat pan is held in place by four (4) bolted on clamps. Keep bolts for re-installation. Now remove the seat wiring harness. LINK Dodge Caravan|Chrysler Town & Country 2008 & up|Passenger FRONT – p.5...
- Page 11 (if present) is attached to the provided bracket #LK-CHRG08L-04 and attached with the unused motor connectors in the seat back. Note: some models may have a control box, this is relocated to the seat back. LINK Dodge Caravan|Chrysler Town & Country 2008 & up|Passenger FRONT – p.6...
- Page 12 Run the power from the battery to the LINK. To do this, thread the red power cable (+) under the doorstep molding and through the firewall. Make sure you pass through a grommet in the firewall to prevent the cable from chaffing. Install the circuit breaker near the battery and then connect the battery to the circuit breaker.
- Page 13 Remove the LINK from the shipping box and set it on a table or workbench. Connect auxiliary 12V power to the LINK. The LINK will ‘beep’ during the installation. (See LINK Audible Warnings chart for further references.) Next, connect the LINK to the Android tablet via Bluetooth. Connect the Bluetooth module (small, blue and white, 4 pronged connector) to the LINK pendant plug.
- Page 14 11. Place the LINK in the vehicle on the floor adapters. Use the four longer (3/8’’-16 x 1¼’’) socket cap bolts to secure the LINK by the pivot, and use the four shorter (3/8’’-16 x 7/8’’) bolts to secure the interior of the LINK.
- Page 15 Drill four holes to be able to pass zip ties. The loosely install the zip ties around the rear bar of the seat adapter. LINK Dodge Caravan|Chrysler Town & Country 2008 & up|Passenger FRONT – p.10...
- Page 16 Remove the top portion of the clip as these will not be required to fasten the seat pan with the installation of the LINK. Do the same for the two (2) black clips towards the rear. LINK Dodge Caravan|Chrysler Town & Country 2008 & up|Passenger FRONT – p.11...
- Page 17 Run the wiring extension out of the bottom right hand corner of the seat. Attach it securely with the provided zip ties. LINK Dodge Caravan|Chrysler Town & Country 2008 & up|Passenger FRONT – p.12...
- Page 18 20. Using the LINK IT application, use ‘BYPASS’ mode to ‘TILT’ the seat adapter up to facilitate the installation of the seat cushion and seat back onto the LINK seat adapter. Install the seat belt receiver onto the LINK. Place the seat back in position ready to be installed onto the seat adapter, run the seat connecter switch under the seat cushion to the approximate place where it will be reconnected.
- Page 19 22. Using the LINK IT application, use ‘BYPASS’ mode to ‘TILT’ the seat adapter up to facilitate the installation of the seat cushion onto the LINK. Place the seat pan onto the LINK. Use the four (4) OEM seat bots to secure the pan onto the LINK seat adaptor.
- Page 20 24. The right hand side seat trim will have to be modified before re-installation to allow clearance for the LINK. Follow the steps in the photos. LINK Dodge Caravan|Chrysler Town & Country 2008 & up|Passenger FRONT – p.15...
- Page 21 25. Install the provided plastic door edge to the flat plate on the side where it bolts to protect the seat belt. Reattach the flap at the lower back of the seat and then tighten down the previously installed zip ties and then reinstall the seat back. LINK Dodge Caravan|Chrysler Town & Country 2008 & up|Passenger FRONT – p.16...
- Page 22 7/16-20x1’’ ½ bolt and washers. Place the washers on either side of the 28. Install the seat belt, seatbelt and then bolt the seat belt to the link base. LINK Dodge Caravan|Chrysler Town & Country 2008 & up|Passenger FRONT – p.17...
- Page 23 29. Secure the seatbelt receiver to the side of the LINK seat adaptor using the OEM bolt from step #3. NOTE: On a seat with manual controls, the seat belt receiver bracket will require a self-tapping screw to fasten in place.
- Page 24 31. Pass the extension wire from the back of the seat under the LINK to the floor harness connector. (Note: Depending on the size of the connector, you may have to unbolt the four interior bolts to pass the extension LINK .) Make sure that there is enough loose in the wire harness for the LINK to travel.
- Page 25 Unplug the Bluetooth module and plug in the hand pendant. Make sure the LINK hand pendant is working properly. Cycle the LINK in and out a few times, both with and without a passenger to make sure all shrouds are properly installed and that nothing is rubbing or requires adjustment. Make a visual inspection while the LINK is in movement that all the wiring follows the seat and does not risk being severed at any time.
- Page 26 A sa fe g ua rd a g a inst the a p p lic a tio n o f e xc e ssive fo rc e o n the O ve rlo a d me c ha nic a l c o mp o ne nts o f the LINK . T he o ve rlo a d p ro te c tio n BEEEEEP Pro te c tio n p re ve nts d a ma g e to the unit.
-
