REQUIREMENTS
Ready-to-Use Chemical Solution
(Minimum 35 PSI at the Unit)
Temperature
Pressure
Flow
Supply Line
Hose
Nozzle
OPTIONS
Large Stainless Steel Hose Rack
Strainer
SS "Y" Strainer
Overview
The Pump Fed Sanitizer is a spray applicator for applying chemical solutions, such as sanitizers in food processing facilities, to a variety of surfaces at 1.7
GPM @ 40 PSI. This unit receives ready-to-use chemical solution from a central chemical feed system and projects it through the hose, wand and fan nozzle.
Alternate flow rates are available upon request.
AFCO • 5000 Letterkenny Rd • Chambersburg, PA. 17201 • 1-800-345-1329
Installation & Operation Instructions
Model #AF 919155 •Pump Fed Sanitizer
up to 160°F
35 - 125 PSI
1.7 GPM @ 40 PSI
1/2"
1/2'' x 50'
2520
# 224150
# 150350
AFCO
http://www.afcocare.com
READ ALL
INSTRUCTIONS BEFORE
USING EQUIPMENT!
Advertisement
Table of Contents
Related Manuals for AFCO AF 919155
Summary of Contents for AFCO AF 919155
- Page 1 GPM @ 40 PSI. This unit receives ready-to-use chemical solution from a central chemical feed system and projects it through the hose, wand and fan nozzle. Alternate flow rates are available upon request. AFCO • 5000 Letterkenny Rd • Chambersburg, PA. 17201 • 1-800-345-1329...
- Page 2 AF 919155 • Pump Fed Sanitizer Safety & Operational Precautions Flow Rate Chart For proper performance do NOT modify, substitute nozzle, hose diameter Pressure Flow Rate or length. Manufacturer assumes no liability for the use or misuse of this unit.
- Page 3 AF 919155 • Pump Fed Sanitizer - Page 3 -...
- Page 4 Troubleshooting Guide AF 919155 • Pump Fed Sanitizer Possible Cause / Solution Problem Startup Maintenance A) Weak pressure or will not spray 1, 2, 3, 4 5, 6 Possible Cause / Solution Startup Maintenance 1. Inlet or discharge ball valves not completely open 5.
