Balancing individual cells battery discharging
It also can monitor and balance individual cells of the Lithium battery pack during the discharge process. If
the voltage of any cell varies abnormally, the process will be stopped with an error message.
Adaptable to various types of Lithium battery
It can accept any Lithium batteries: Lilon, LiPo, LiFe and LiHv. They have different characteristics by
their chemistry. You can select any one of them that you are going to process before the job. For their
specifications, refer to "Warnings and safety notes" section.
Lithium battery "Fast" and "Storage" mode
You can charge Lithium battery for special purposes. "Fast" charge reduces the charging time of Lithium
battery and "Storage" mode controls the final voltage of the battery to be suited for long time storage.
Maximum safety
• Delta-peak sensitivity: The automatic charge termination program works on the principle of the Delta-peak
voltage detection (NiCd/NiMH). When the battery's voltage exceeds the threshold, the process will be
terminated automatically.
• Auto-charge current limit: When charging NiCd or NiMH at "AUTO" current mode, you can set the upper
limit of charge current to avoid from high current charging. This is very useful when charging the low
impedance and small capacity NiMH battery in "AUTO" mode.
• Capacity limit: The charging capacity is always calculated by multiplying the charging current and time.
If the charging capacity exceeds the limit the process will be terminated automatically when you set the
maximum value.
• Temperature limit: The temperature of the battery on charging will rise by its internal chemical reaction.
If you set the limit of temperature the process will be expired forcibly when the limit has been reached.
* This function is available by connecting optionnal temperature probe, which is not included in our
package
• Processing time limit: You can also restrain the maximum process time to prevent from any possible defect.
• Input power monitor: To protect the car battery using as DC input power from being damaged the
voltage of it always monitored. If it drops below the lower limit the process will be ended automatically.
Data store/load
For users convenience it can store maximum 5 data of different batteries. You can establish the data
contains program setting of the battery to charge or discharge continually. These data can be called out
at any time you need and the process can be executed without program setting.
Cyclic charging/discharging
Perform 1 to 5 cycles of charge> discharge or discharge> charge continually for battery refreshing and
balancing.

WARNINGS AND SAFETY NOTES

Those warnings and safety notes are particularly important. Please follow the instructions for a maximum
safety; otherwise the charger and the battery can be damaged violently. And also it can cause a fire to
injure a human body or to lose the property.
1. Never leave the charger unsupervised when it is connected to its power supply. If any malfunction is
observed immediately terminate the process and refer to the operation manual.
2. Keep away the charger from dust, damp, rain, heat direct sunshine and vibration. Do not drop it.
