- Page 1 Lift “F900” Operation and Maintenance Manual www.autoliftsrl.com...
-
Page 2: Main Parts
Lift “F900” 1-SAFETY Always take following safety precautions when using the Lift F900: A-The vehicle must be parked in a flat ground. If the vehicle is parked on a slop, the use of the lift could be dangerous. B- The vehicle must always be safely parked, with emergency brake engaged before using the lift. - Page 3 Lift “F900” 4- HOW TO OPERATE THE LIFT Before using the lift, the vehicle must be safely parked with emergency brake engaged and warning flashing lights on. The operation is done through the Hand Control : Platform “UP” Platform “DOWN”...
- Page 4 Lift “F900” 4.2 How to get off the car “OUT” until the platform is completely out of the box -Push “UP” and raise the lift up to the vehicle floor level -Push -Wheelchair occupant moves from the vehicle cabin on the platform “DOWN”...
-
Page 5: Emergency Operations
2. Move lever up and down 3. Using the hand pump lift the platform to the required height 4. Put the lever back in to its fixation 5. Contact an Autolift distributor or service point Picture-1 Picture-2 5.3 Emergancy Lowering 1. - Page 6 2. Move lever up and down 3. Using the hand pump lift the platform to the required height 4. Put the lever back in to its fixation 5. Contact an Autolift distributor or service point Picture-1 Picture-2 5.3 Emergancy Lowering 1.
-
Page 7: Checks And Maintenance
6.1 CHECKS Check before and after installation The Underflor Lift F900 was previously checked in Autolift before dispatch. After Installation in to the vehicle a trained person will have to do the described checks and confirm it on the attached Document. - Page 8 Lift “F900” 6.2 SETTINGS By changing the position of the cams it is possible to re-set the central position level and the upper position (vehicle floor level) Microswitch C MICROSWITCH A Microswitch A Microswitch B regulate the central position level...
- Page 9 Lift “F900” 6.3 POSSIBLE FAILURES First check that the battery level is acceptable Failure Ev. Cause Solutions 1.Platform does’t get out of box 1.Hand control not working 1.Check hand control and ev. change it 2.Microswitcht A is not working 2.Move manually the microswitch 2.Platform is on the floor and...
-
Page 10: Technical Datas
Lift “F900” 8- TECHNICAL DATAS TECHNISCHE DATEN TECHNICAL FEATURES Model: F900 Model: F900 Tragkraft: 300 Kg Loading capacity 300Kg Eigengewicht: 135Kg Weight: 135Kg Spannung: 12 Volt Electrical System: 12 Volt Oeldruck max: 200 Bar Max Air Presure: 200 Bar Piattaformgroessen: 800 x 1250mm... -
Page 11: Hydraulic Diagram
Lift “F900” 9 -HYDRAULIC DIAGRAM The hydraulic unit is built in a protection box and can be placed inside the vehicle in preferred position. The emergency pump and emergency lowering valve are accessible with out removing the box cover and this... -
Page 12: Electric Diagram
Lift “F900” 10 – ELECTRIC DIAGRAM Control Unit (Printed circuit) Power Unit POSITION CORRESPONDANCE Platform El. Motor Flashing lights TLRS Starting Relais Acustic Warning Lowering valve Entra Platform in Esce Platform out Microswitch for Platform Height Microswitch for Platform Height... -
Page 13: Exploded View
Lift “F900” 11 – EXPLODED VIEW... - Page 14 Operation and Maintanance Manual For a correct and safe use of the lift please read carefully this manual www.autoliftsrl.com...
