Thank you for your wise choice of our distinguished electric hoist. For your better understanding of the performance of this model, Operational safety and inspection, please read carefully and keep this manual in a safe place. SAN YUAN ENTERPRISE CO., LTD...
Page 2
CAUTIONS IN OPERATION AND MAINTENANCE An electric hoist has been used as a safe and convenient machine to save time and labor in operation. Before use, however, careful attention must be paid to operational safety and inspection procedures. Therefore, before operating this electric hoist, please read the following instructions and follow correct operational methods.
Page 3
(C)CAUTIONS FOR THE USE OF ELECTRICAL HOIST For the sake of safety, do not apply a load in excess of the rated load. Ensure if the load is tightly fastened? Before applying the load, the chain(Wire ROPE)must be straightened to buffer the impact.
Page 4
Is the hoist operation smooth? Is there abnormal noise when it is with load? Check if the chain is oiled or damaged? Is the brake operation normal when the winding is stopped? Is the lower hook wasily rotating? D-2 Regular inspection items: Inspection of LINK chain LINK chain is the most important part of the electrical chain hoist, which is made of special alloy steel with heat treatment.
Page 8
CHAIN HOIST PART LIST NO. PART NO. PART NAME SIZE Q,TY NO. PART NO. PART NAME SIZE Q,TY V001 Upper Hook Ass’Y 32 V032 Limit Lever V001-20 2CV 33 V033 Blot φ8 V001-25 3CV 34 V034 S.W. φ8 V001-50 5CV 35 V035 Link Chain V001-75 7.5CV...
Page 9
CHAIN HOIST PART LIST PART NO. PART NO. PART NAME SIZE Q,TY NO. PART NAME SIZE Q,TY 55 V055 Oil Seal 56 V056 Ball Bearing 6209 90 V090 Power Cable 57 V057 Snap Ring 91 V091 Control Box 58 V058 45φ...
Page 10
CHAIN HOIST PART LIST PART PART PART NAME SIZE Q,TY NO. PART NAME SIZE Q,TY 118 V118 Terminal Plate 119 V119 Screw φ4 120 V120 S.W. φ4 121 V121 Control Cable 122 V122 Push Button V122-2 2P Push Button V122-4 4P Push Button V122-6 6P Push Button 125 V125 Cove Stud Bolt...
Page 11
MOTOR TROLLEY CAUTIONS FOR THE USE OF MOTOR TROLLEYS Before mounting the motor trolley on the I-beam, the width of I-beam must be measured. As shown in the following diagram, adjust the clearance between the two wheels of the trolley to the correct position. Then, mount it onto the I-beam and tighten the nuts at two ends.
Page 13
MOTOR TROLLEY PART LIST PART PART PART NAME SIZE Q,TY NO. PART NAME SIZE Q,TY T001 Gear Wheel 11 T011 Rotor Ass'y 1/2T001 1/4MT & 1/2MT 1/2 T010 1/4MT & 1/2MT 1T001 1T010 2T001 2T010 2MT & 3MT 3T001 5T010 5T001 12 T012 Ball Bearing...
Page 14
MOTOR TROLLEY PART LIST PART PART PART NAME SIZE Q,TY NO. PART NAME SIZE Q,TY 27 T027 Distant Ring 35 T035 Control Box 1T027 1/4MT & 1/2MT ST035 1/4MT-5MT 220V OR 380V 2T027 36 T036 Name Plate 5T027 1/4T036 1/4MT 28 T028 Hanger Pin 1/2T036 1/2MT...
