- Page 1 Metallic manual filters User manual FL / FY / FL-PP / FY-EC Serial number: _________________ Purchase date: _________________ (FY) ILTER (FL) ILTER ILTER (FY-EC) YCLONIC FFECT ILTER IVOT (FL-PP) www.itmfilters.com...
-
Page 2: Table Of Contents
FY / FL / FL-PP / FY-EC ANUAL Index User Manual FY/FL/FL-PP/FY-EC Introduction ........................1 Filter identification ....................1 Basic concepts ......................1 Data Sheet ......................... 2 Metallic L Filter (FL-M) ....................2 Metallic Y Filter (FY-M) ....................3 L Filter - Metallic Pivot Foot (FL-PPM) ............... 4 Y Filter - Metallic Cyclonic Effect (FY-EC) .............. -
Page 3: Introduction
FY / FL / FL-PP / FY-EC ANUAL Introduction First of all, we want to thank you for purchasing this filter, the result of the work of a group of people committed to offering the correct solution to each filtration process. All products designed and manufactured by ITM Filters meet self-imposed requirements for quality, efficiency and durability. -
Page 4: Data Sheet
FY / FL / FL-PP / FY-EC ANUAL Data Sheet 2.1 Metallic L Filter (FL-M) Water inlet Water inlet MAGE FL-M load loss Ø2 mm pass FL-M load loss, 125 microns pass Flow (m Flow (m HART HART Working pressure = 10 kg/cm²* Flows (m³/h) Dimensions (mm) Filtration... -
Page 5: Metallic Y Filter (Fy-M)
FY / FL / FL-PP / FY-EC ANUAL 2.2 Metallic Y Filter (FY-M) Water Water inlet inlet MAGE FY-M load loss, Ø2 mm pass FY-M load loss, 125 microns pass Flow (m Flow (m HART HART Working pressure = 10 kg/cm²* Flows (m³/h) Dimensions (mm) Filtration... -
Page 6: L Filter - Metallic Pivot Foot (Fl-Ppm)
FY / FL / FL-PP / FY-EC ANUAL 2.3 L Filter - Metallic Pivot Foot (FL-PPM) Working pressure = 10 kg/cm²* Water inlet MAGE Flow (m³/h) Dimensions (mm) Filtration Filter MODEL ØI/ØO Surface Weight ø2 mm Cartridge opening ØD (cm²) (kg) (Sprinkler) FL-PPM-6"... -
Page 7: Y Filter - Cyclonic Effect - Flow Rates As A Function Of Plugged Orifices
FY / FL / FL-PP / FY-EC ANUAL 2.5 Y Filter - Cyclonic Effect – Flow rates as a function of plugged orifices Flows FY-2’’ – CIC Differential pressure 0,5 kg/cm² • 10 PLUGS 11 PLUGS 12 PLUGS 13 PLUGS Q = 26.8 m³/h Q = 21.6 m³/h Q = 18.5 m³/h... - Page 8 FY / FL / FL-PP / FY-EC ANUAL • Flows FY-4’’ and FY-5’’– CIC Differential pressure 0,5 kg/cm² 0 PLUGS 1 PLUGS 2 PLUGS 3 PLUGS 4 PLUGS 5 PLUGS 6 PLUGS Q=65m³/h Q=63m³/h Q=60m³/h Q=56.8m³/h Q=54.3m³/h Q=51.5m³/h Q=49m³/h 7 PLUGS 8 PLUGS 9 PLUGS 10 PLUGS...
-
Page 9: Manufacturing Technical Characteristics
FY / FL / FL-PP / FY-EC ANUAL 2.6 Manufacturing technical characteristics Materials: o Carbon steel metal components. o Zinc plated screws 6.8. o Mesh cartridge : PVC structure with AISI-316 Stainless Steel. Filtration degree: 125 microns. o Grinding cartridge: AISI-304 Stainless Steel. Ø2 mm pass. o EDPM gaskets: 60 SHORE. -
Page 10: Spare Parts
FY / FL / FL-PP / FY-EC ANUAL Spare parts 5.1 Exploded view Metallic Y Filter (FY-M) FY MODELS Nº DENOMINATION FY4-165 Code Code Code Body FY-2-02 FY-3-02 FY-4-165-02 Plug Lower Gasket FY-2-08 FY-2-08 FY-2-08 Mesh Cartridge-Drip FY-2-04 FY-3-04 FY-3-165-04 Cartridge ø2 - Sprinkler FY-2-03 FY-3-03... -
Page 11: Exploded View Metallic L Filter (Fl-M)
FY / FL / FL-PP / FY-EC ANUAL 5.2 Exploded view Metallic L Filter (FL-M) FL MODELS Nº DENOMINATION FYL-4-165 Code Code Code Body FL-2-02 FL-3-02 FL-4-165-02 Plug Lower Gasket FY-2-08 FY-2-08 FY-2-08 Mesh Cartridge-Drip FY-2-04 FY-3-04 FY-4-165-04 Cartridge ø2 -Sprinkler FY-2-03 FY-3-03 FY-4-165-03... -
Page 12: Exploded View L Filter - Metallic Pivot Foot (Fl-Ppm)
FY / FL / FL-PP / FY-EC ANUAL 5.3 Exploded view L Filter – Metallic Pivot Foot (FL-PPM) FL-PPM MODELS Nº DENOMINATION FL-PPM-6 FL-PPM-8 FL-PPM-10 FL-PPM-12 Code Code Code Code Body FL-PPM-6-02 FL-PPM-8-02 FL-PPM-10-02 FL-PPM-12-02 Plug Hex nut. M16 DIN934 DIN934 DIN934 DIN934... -
Page 13: Exploded View Y Filter - Cyclonic Effect (Fy-Ec)
FY / FL / FL-PP / FY-EC ANUAL 5.4 Exploded view Y Filter – Cyclonic Effect (FY-EC) FL MODELS Nº DENOMINATION FY-EC-2 FY-EC-3 Code Code Body FY-EC-2-02 FY-EC-3-02 Plug ¼ ‘’ Lower Gasket FY-2-08 FY-2-08 Plug FY-EC-2-08-01 FY-EC-2-08-01 Cyclonic Effect Disc FY-EC-2 FY-EC-2 Mesh Cartridge-Drip... -
Page 14: Product Warranty
FY / FL / FL-PP / FY-EC ANUAL Product warranty 1. All ITM FILTERS products are guaranteed for 1 year from the date of invoice. 2. The replacement of defective parts is covered by the warranty, being necessary to indicate the serial number and allow the verification by our staff. 3.
