Quick Start Guide
Dual 7" Screen Portable DVD Player
S71PDT12E
Thank you
for purchasing your new
Sandstr m DVD Player.
Ø
Please follow this quick start guide for a
successful first time set up.
We recommend that you spend some
time reading the instruction manual in
order to fully understand all the opera-
tional features it offers.
Read all the safety instructions carefully
before use and keep the instruction
manual for future reference.
1

Unpacking

Remove all packaging from the unit. Retain the packaging.
If you dispose of it please do so according to any local regulations.
DVD Player Monitor
Mains Adapter Car Power
Adapter
Car Mounting Straps x 2 Instruction Manual
2

Operating Your Remote Control

1. Slide and hold the battery release tab in the
direction of the arrow.
2. Pull out the battery holder and remove the old
battery.
GB
3. Replace with a new battery.
4. Insert the battery holder back into the remote
control.
Install the batteries correctly by following the
polarity (+ and –) indications in the battery
compartment.t
3

Connecting to the Mains Supply

The mains adapter (DC12V output)
supplied is only for using the DVD
Player and the Monitor together.
4

Using in a Car

Connecting for in-car Use
The included 12V car power adapter is designed for use with vehicles that have
a 12V electrical system.
Remote Control
(with battery)
SOURCE DISPLAY REPEAT/ REPEAT
PROG A-B
AUDIO/
ANGLE
SUBTITLE/
TITLE
MENU/ ZOOM
/ SETUP
SLOW
OK GOTO
DVD Player
(Right side)
3.5mm to 3.5 mm
AV Cable
Quick Start Guide
1
2
3
4
Mains Adapter (Included)
Power adaptor
DVD Player
Monitor
To the
(Right side)
(Left side)
mains
socket
To DC IN
12V Socket
To DC IN
12V Socket
Monitor
(Left side)
Car Power Adapter
(Included)
To DC IN
12V Socket
To A/V IN
Sockets
To A/V OUT
Sockets
To DC IN
12V Socket
3.5mm to 3.5mm
AV cable (Included)
5

Mounting in a Car

Thread the strap ends Loop the strap around the
1 2
through the strap eyelets. headrest, with the DVD Player
facing the rear seat, then
fasten the strap with the clip.
Installation Guide
DVD Player
Mounting
Strap
3.5mm to
3.5mm AV
cable
SOURCE DISPLAY REPEAT/ REPEAT
PROG A-B
AUDIO/ ANGLE
TITLE SUBTITLE/
MENU/
ZOOM
SLOW / SETUP
OK GOTO
6

Basic Playback

DVD Player
1. Slide the ON/OFF switch to the ON
(Right side)
position.
2. Lift the LCD display to open the disc
cover.
3. Hold the disc by its sides and
carefully place onto the disc holder
with the label side facing up. Gently
push the disc down until you hear a
"click" sound.
4. Close the disc cover. Use the stand
located at the rear of the unit or hold
the DVD player in your hands (be
careful not to touch the unit's disc
door). The unit starts playback if the
disc does not have any menus
recorded on it. If the disc has one or
more titles recorded on it, a menu
screen will appear on the screen.
5. To play a title, press the / 0-9 buttons on the remote control to
highlight the title and then press the OK button on the unit or the
remote control.
You will find that there are many exciting features available.
Tip:
To get to know all these features, please take some time to read
the instruction manual provided.
Monitor
Mounting
Strap
Car Power
Adapter
Remoter Control
Monitor
(Left side)
Power
switch
