- Page 1 Instruction Manual TSP-jr Almen Gage Electronics Inc. 56790 Magnetic Drive Mishawaka, Indiana 46545 1-800-832-5653 (Toll Free) Phone: 1-574-256-5001 Fax: 1-574-256-5222 Made in the USA E-mail: sales@electronics-inc.com Website: www.electronics-inc.com IM:0070 Date: 2017-06-30...
- Page 2 Table of Contents 1. DESCRIPTION 2. QUICK START 3. GENERAL INFORMATION 4. MAINTENANCE 5. CALIBRATION 6. WARRANTY...
- Page 3 1. Description The TSP-jr Almen Gage is a precision device used for measuring the deflection or curvature of a metal test coupon called an Almen strip. It is fitted with a calibrated high accuracy analog indica- tor with a low-force spindle spring to provide highly accurate and repeatable measurements.
- Page 4 Common limits of pre-bow (flatness) MIL-S-13165 0.038mm or 0.0015” Grade 3 or 2 Almen strip SAE J 442 0.0254mm or 0.001” Grade A1 Almen strip SAE AMS 2432 0.0127mm or 0.0005” Grade A1-S Almen strip 3. General Information A Placement of strip onto gage for correct reading—the indicator tip touches the non- peened side of the strip.
- Page 5 DO NOT APPLY ANY OIL OR OTHER LUBRICANTS TO THE INDICATOR. 5. Calibration A specially designed calibration kit is available from Electronics Incorporated. Kit part number 999430 is used for inch calibrations. Kit part number 999431 is used for metric calibrations.
- Page 6 The #2 Almen gage is warranted to be free from defects and materials for a period of one (1) year from date of shipment from Electronics Incorporated. Any problems, other than customer abuse or normal wear will be corrected free of charge. Send the gage with freight pre-paid to:...
