- Page 1 PowerLight Butterfly Cordless LED light Instructions for Use Read this document carefully before using the product. © 2019-2020 Admetec Solutions ltd. All rights reserved.
-
Page 2: Table Of Contents
Table of Contents Table of Contents Introduction ................3 Intended Use ..............3 About Butterfly ..............3 Safety Precautions .............. 4 Troubleshooting ..............4 Product Overview ..............5 Battery Charger .............. 5 Battery Pack ..............7 Headlight ................ 8 Technical Specifications ............ 12 Battery Charger ............ -
Page 3: Introduction
Intended Use Butterfly is a cordless headlight system designed to provide illumination during dental or minor surgical procedures. The Butterfly is part of the Admetec PowerLight product family. Using a battery pack gives the user complete portability allowing unrestricted movement. -
Page 4: Safety Precautions
Product overview Safety Precautions Butterfly Do not use any third-party chargers with Battery Packs, even if they look identical. Third-party chargers are not compatible with the battery packs and could damage it. Prevent battery packs from overheating. Avoid direct sunlight or heated surfaces. -
Page 5: Product Overview
Butterfly – Instructions for Use Product Overview Figure 1: Butterfly Light Kit The Butterfly kit includes: Battery Charger Charging cable Charging pad 3 battery packs Headlight External orange filter Screwdriver Battery Charger To charge the battery,... - Page 6 Product overview Connect Charging pad to charger using the provided cable. Plug the charger into a wall outlet. Place the battery pack on the charging pad as shown in Figure 2. It is possible to charge two battery packs simultaneously. The charging indicator will light red.
-
Page 7: Battery Pack
Butterfly – Instructions for Use Battery Pack Each Butterfly kit includes 3 battery pack units serving as power source and control panel for the headlight. Figure 3: Battery Pack: Top View Battery packs control – turning the light source ON and OFF. This function is controlled by touching the area marked in green in Figure 3. -
Page 8: Headlight
Product overview Dimming the light source in two different intensities is controlled by touching the area on the right side of the battery, marked in green on the Figure 3.1. Figure 4: Connection (Bottom) Panel Notes The battery pack supports a constant level of light intensity during the whole period of discharging. - Page 9 Butterfly – Instructions for Use To Use Butterfly: Mount the external orange filter onto the front part of light source by pushing the outer ring of the filter onto the front part of the light source as shown in Figure 5. Figure 5: Mounting External Filter Attach the light source to the mechanical connector on the loupes frame or on the universal clip as shown in Figure 6...
- Page 10 Product overview Figure 7: Light Source Attached To Universal Clip Place the battery pack on the connection pad. The battery pack must be oriented so that the Butterfly logo faces ahead. The magnets will align the battery electrodes with the connection pad.
- Page 11 Butterfly – Instructions for Use Figure 9: Headlight Assembled on Loupes Frame Adjust angle of the light direction to get light beam visible through the loupes.
-
Page 12: Technical Specifications
Product overview Technical Specifications Battery Charger 100 – 240 V AC Input voltage Output voltage 5 V DC Battery Pack Internal battery voltage: 3.7 V Battery capacity: 0.56 Ah Full battery charging time 1.5 hours Average working time 2 hours Length 50 mm Width:... -
Page 13: Warranty
(1) year for all other supplied parts from the date of original purchase ("Warranty Period"). If a defect arises and a valid claim is received by Admetec within the Warranty Period, Admetec will (1) repair the product at no... - Page 14 Batch number Catalog number If you have purchased Admetec-branded electrical or electronic products in the EU and are intending to discard these products at the end of their useful life, please do not dispose of them with your other household or municipal waste.
