ThinkRF R5500 Quick Start Manual

Hide thumbs Also See for R5500:

Advertisement

Quick Links

Download this manual
Precautions & Quickstart Guide
R5500
Precautions & Quickstart Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the R5500 and is the answer not in the manual?

Questions and answers

Related Manuals for ThinkRF R5500

Summary of Contents for ThinkRF R5500

  • Page 1 Precautions & Quickstart Guide R5500 Precautions & Quickstart Guide...

  • Page 2: Important Notice

    ThinkRF Corporation. Trademarks ThinkRF, the ThinkRF logo and R5500 are trademarks of ThinkRF Corporation. All other brand or product names are trademarks or registered trademarks of their respective companies or owners.

  • Page 3: Obtaining Technical Assistance

    R5500 serial number and product version which are located on the identification label on the R5500’s underside. • The firmware version running on the R5500 which can be found by typing your connected device’s IP address into a web browser. •...
  • Page 4 Always follow these steps to prevent ESD. Warning: Never open the front or rear panels of the R5500 as personal injury may result and opening the chassis will void the warranty. There are no user-serviceable parts inside. Always contact ThinkRF support for service.
  • Page 5 See below for the maximum allowable input and cautions. Connect one end of the Ethernet cable to the R5500’s Ethernet port and the other end to an Ethernet port on your router or PC. Connect the R5500 to its power adapter or battery pack (optional).
  • Page 6 As well, this 10 MHz is redistributed within the R5500 and sent to the 10 MHz OUT SMA connector for use by external equipment that needs a 10 MHz reference source.
  • Page 7 When used on a desktop or mounted in a rack, cabinet or enclosure, one must provide cooling to the R5500 by air convection across the embedded chassis’s top surface or via heat conduction by mounting the embedded chassis’s top surface to an appropriate heat conducting surface, capable of 15W of power dissipation.

  • Page 8: Getting Started

    Precautions & Quickstart Guide Getting Started Shipping Box Contents Please ensure that your shipping box contains the following: • R5500 Real-Time Spectrum Analyzer • Power adapter and associated power cable • Straight-through Ethernet cable • USB flash drive with associated documents and software •...
  • Page 9 USB console port. The R5500 provides a means for obtaining an IP address dynamically using DHCP or the manually setting of a static IP address. The unit is set to use DHCP by factory default or on factory reset.
  • Page 10 DHCP” and click the “Apply” button. Alternatively, performing a reset to factory settings will reset the R5500’s IP configuration to obtain an IP address dynamically using DHCP. Perform this procedure if for any reason you can not connect to the R5500 via the Ethernet.
  • Page 11 Precautions & Quickstart Guide 2. Power on the R5500 3. At any time while the R5500 is powered on, press and hold the reset button (located in The Rear Panel) for at least 5 seconds by inserting a paper clip or similar object 4.
