Terra Bound Solutions DURA Assembly Instructions

STEP 1: PLACE THE 2 (OR 3 DEPENDING ON MODEL)

Surface Mount LEGS FACING UPRIGHT ON A LEVEL
SURFACE SO THE MOUNTING BRACKETS ARE FACING
TOWARD THE INSIDE. (ESTIMATE SPACING).
STEP 2: PLACE A 4" X 4" PROFILE OVER ONE OF THE 2
INSIDE SET OF HOLES ON THE SURFACE MOUNT LEGS,
MAKING SURE THE "MOLD" SEAM IS FACING DOWN.

STEP 3: SLIDE PROFILE TO ALIGN HOLES WITH THE

CORRESPONDING HOLES OF THE SURFACE MOUNT LEGS.

STEP 4: INSERT BOLTS THROUGH EACH HOLE IN THE

PROFILE INTO THE SURFACE MOUNT LEGS. PLACE A FLAT
WASHER AND FLANGE NUT ONTO THE BOTTOM OF EACH
BOLT – HAND TIGHTEN ONLY.
STEP 5: PLACE THE REMAINING 4" X 4" PROFILES ON THE SURFACE MOUNT LEGS, MAKING SURE THE "MOLD" SEAM IS
FACING DOWN. REPEAT STEPS 3 & 4.
STEP 6: ONCE ALL BOLTS, WASHERS, AND NUTS ARE IN PLACE, TIGHTEN BOLTS SECURELY WITH A 3/8" DRIVE
RATCHET WITH A ½" DEEP WELL SOCKET (SHIFTING YOUR BENCH WHERE NECESSARY TO INSURE A NEAT SQUARE
APPEARANCE).
OPTIONAL: THE BENCH CAN BE SECURED TO EITHER CONCRETE OR ASPHALT WITH FOUR STANDARD ½" MASONRY
FASTENING DEVICES (NOT INCLUDED) USING THE MOLDED-IN METAL BRACKETS ON THE BOTTOM OF THE SURFACE
MOUNT LEGS.
AND YOU MAY NEED TO TURN THEM END-FOR-END IF THEY DO NOT LINE UP SQUARELY.
Your 100% recycled plastic park bench will give you many years of pleasure and pride,
knowing that you did your part in keeping plastic waste out of landfills and protecting our environment.

NOTE: PROFILES MAY BE DIRECTIONAL

ASSEM BLY I N ST RU CT I ON S
SU RFACE M OU N T FLAT BEN CH
4' 6'
REF# QTY QTY DESCRIPTION
1 2 3 SURFACE MOUNT BENCH END
2 4 4" X 4" X 4' PROFILE
2 4 4" X 4" X 6' PROFILE
HARDWARE KIT
3
8 12
4 8 12
5 8 12
5/16" X 7" CARRIAGE BOLT
5/16" FLAT WASHER
5/16" FLANGE NUT
