46" Round Carousel Picnic Table
1
Fix the 6 legs to the leg support frame.
2
Parent Model # 277590BK/BL/GN
Picnic Table Top: 277CP59BK/BL/GN
Picnic Seats: 277CP60BK/BL/GN
Base & Legs: 277CP61
1
1
CONTENTS
Ref.
Qty.
Leg
1
6
1
2
Leg Support Frame
1
3
Table Top
Seats
6
4
M8*25 Hex Bolt
30
H1
M8 Nut
H2
42
H3
84
Washer
H4
1
M8*30 Hex Bolt
12
M8*20 Hex Bolt
H5
6
H6
Expanion screw kit
Detail 1
Description
Per Set
H5 (x1)
H2 (x1)
H3 (x2)
Advertisement
Table of Contents
Related Manuals for Global 277590BK
Summary of Contents for Global 277590BK
- Page 1 46" Round Carousel Picnic Table Parent Model # 277590BK/BL/GN Picnic Table Top: 277CP59BK/BL/GN Picnic Seats: 277CP60BK/BL/GN Base & Legs: 277CP61 CONTENTS Ref. Qty. Description Leg Support Frame Table Top Seats M8*25 Hex Bolt M8 Nut Washer M8*30 Hex Bolt M8*20 Hex Bolt Expanion screw kit Fix the 6 legs to the leg support frame.
- Page 2 Assembly Instructions 46" Round Carousel Picnic Table Detail 2 Attach table top to legs. Per Set H1 (x1) H2 (x1) H3 (x2)
- Page 3 Assembly Instructions 46" Round Carousel Picnic Table Attach seats to legs. Note that the leg brackets gets fastened Multiple holes on the chair allows in between the chair bracket. seating space to be adjusted closer or farther from table. Attach hex bolt to leg support. Fix picnic table to ground.
