GE TFX26PPD Dimension Manual

TM
TFX26PPDWW—GE Profile
Dimensions (in inches)
A B
Note: If the doors cannot be fully opened because of an obstruction or a
wall on either side, a door stop should be provided to prevent door or wall
damage. If the doors cannot be opened at least 90 degrees, access to the
drawers is limited.
Specification Created 2/00
™ 25.6 Cu. Ft. Side-by-Side Refrigerator with Dispenser
H
G
C
D

Top View

For answers to your Monogram,
GE Profile Performance Series,
GE Profile
GE Answer Center
VOLUME and
SHELF AREA
Manufacturer Certified to
ASSOCIATION OF HOME
APPLIANCE MANUFACTURERS
ANSI/AHAN HRF-1-1979
Height with hinge (in.) A
Height without hinge (in.) B
Depth without Doors (in.) C
Depth with Doors (in.) D
Depth plus Handle with Doors Closed (in.) E
Depth with Doors open 90° (in.) F
E Width with Doors Closed (in.) G
F
Width with Doors open 90° Less Door Handle(in.) H 36-1/8
Each side (in.)
Top (in.)
Back (in.)
† If installed against a wall, allow clearance of 11-1/4" on freezer side to
remove ice bin.
To remove fresh food pans, remove door bins.
13-5/8" Clearances required to remove fresh food full-size pan
without disassembling.
For Built-In apperance, allow height space of 69-3/4" on 26 cu. ft.
Plus, allow additional space for any necessary leveling adjustments
®
™
™ or GE appliance questions, call
® service, 800.626.2000.
Total volume and shelf
area are calculated by the
Listed by
Association of Home
Underwriters
Appliance Manufacturers'
Laboratories
R
standards.
®
C US
Today's GE refrigerators use about 50% as much
energy as refrigerator models made in 1980.
69-3/4
68-3/4
28
30-1/4
32-1/2
49-3/8
35-3/4
3/4 †
1
1
