ALZO Video SHOCK MULTI-MOUNT User Manual

ALZO SHOCK MULTI-MOUNT USER GUIDE

COMPONENTS

1. Large Cage
2. Small Cage
3. Connecting bar
4. Shoe Mount
5. Mounting hardware kit

ASSEMBLY

The ALZO SHOCK MULTI-MOUNT can be assembled in
many configurations. The most common assembly has the 2
cages facing the same direction as shown below. In order
to accommodate different equipment, you may need to
reposition the parts to achieve the optimal arrangement.
The cages are mounted to the connecting bar with the
supplied cap screws, lock washers and the 5/32" Allen
wrench. Screws must enter the thin side of the cage mount
as shown. On first assembly the screws must be tightened
VERY firmly to compress the cage mount over the
connecting bar. This will prevent movement of the cages.
The connecting bar has several holes to allow for
repositioning the shoe mount. The shoe mount can be
repositioned to adjust the balance of the device when
loaded with gear.

USAGE GUIDE

The ALZO SHOCK MULTI-MOUNT is an accessory
mounting device that can be used with either a DSLR
camera or CAMCORDER. In addition, the device can be
used mounted on a tripod or a light stand.
The device is designed with a large cage with 4 standard
cold shoe mounts and 5 ¼" mounting holes to allow the user
many accessory mounting options. Although the small cage
has short shoe mounts like the large cage, these are not full
size and we do not recommend using them as shoe mounts.
Typical accessories may include a microphone, audio mixer,
audio recorder and/or a camera light.
