OPERATION, SERVICE AND
MAINTENANCE INSTRUCTION
DUCT FURNACE MODULE
3035443
ANSI Z83.8 (2016) – CSA 2.6M (2016) Gas-Fired Duct Furnace
!
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury,
death or property damage.
Be sure to read and understand the installation, operation and service
instructions in this manual.
Improper installation, adjustment, alteration, service or maintenance can
cause serious injury, death or property damage.
Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
·
Do not try to light any appliance
·
Do not touch any electrical switch; do not use any phone in your building
·
Leave the building immediately
·
Immediately call your gas supplier from a phone remote from the
building. Follow the gas supplier's instructions.
·
If you cannot reach your gas supplier, call the fire department.
Installation must be performed by a qualified installer, service agency or gas
supplier
This manual must be kept with the appliance for future reference.
Heatco Inc.
50 Heatco Court
Cartersville, GA 30120
HM and HH SERIES
WARNING:
.
MP5157
H(M,H)-USM-MAN-E-2016-12
Advertisement
Table of Contents
Related Manuals for heatco HM Series
Summary of Contents for heatco HM Series
- Page 1 If you cannot reach your gas supplier, call the fire department. Installation must be performed by a qualified installer, service agency or gas supplier This manual must be kept with the appliance for future reference. Heatco Inc. 50 Heatco Court Cartersville, GA 30120 H(M,H)-USM-MAN-E-2016-12...
-
Page 2: Table Of Contents
The information provided in this manual applies to the furnace module installed as part of a manufactured package system and to its operation, maintenance, and service. Refer to the system manufacturer’s instructions for information related to all other components. Table of Contents Installation…………………………………………………………………..3 Combustion Air Supply …………………………………………………..3 Furnace Module Component Identification………………………..….4... -
Page 3: Installation
Installation Verify the following before placing the equipment into service: 1. Electrical supply matches the voltage marked on the furnace module Rating Plate. 2. Gas supply provided matches the Gas Type marked on the furnace module Rating Plate. 3. Furnace module is installed in orientation marked on vestibule. Orientation is specific to airflow direction through the heating section of the unit. -
Page 4: Furnace Module Component Identification
Figure 1 - Furnace Module Component Identification Combustion Air Modulator Valve Pressure Switch (Modulating systems only) Flame Rollout Two-Stage Switch Gas Valve Flame Sensor Gas Inlet Hi Limit Switch Connection Manifold Pressure Tap Induced Draft Fan Assy. Draft Inducer Motor Spark Igniter Motor Support Bracket... -
Page 5: Gas Supply Piping And Connections
In furnace modules with bottom mounted horizontal burner, condensate will drain from the open end of the tubes. A condensate collection pan which attaches to the burner assembly is available as an option. Additionally, condensation typically forms on exterior surfaces, such as the furnace vestibule panel (header plate), in contact with the conditioned air. -
Page 6: Venting Outdoor Installations
The duct furnace module gas piping was leak tested prior to shipping. However, during shipping and installation connections may have loosened. Check for leaks using a soap solution and correct any leaks before placing furnace in operation. WARNING! WARNING! All field gas piping must be pressure / When pressure testing at ½... -
Page 7: Venting Indoor Installations
Figure 5 Field Starkap or equal listed Vent cap 12 in. Min Caution! Flue gases must be directed 4 ft. Min. away from combustion air inlets, to avoid recirculation into combustion air supply. Rectangular to Round adapter Combustion Air Opening Condensate Cabinet Drain... -
Page 8: Horizontal Venting - Category Iii
6 – Indoor Vertical Venting Figure Listed Vent Terminal Use Insulated Vent Outdoors Thimble Roof 18 in. Min. (457 mm) 1/4in. (6mm) pitch per “H” 1ft. (305mm) Vertical Height horizontal run Condensate See Table 1 for minimum Drain vent diameter for input rating “L”... -
Page 9: Separated Combustion
Through the wall vents shall not terminate over public walkways, or over an area where condensate or vapor could create a nuisance or hazard. Provide minimum vent termination clearances to building or structure features as follows: Structure Minimum Clearance Door, Window or gravity inlet 4 ft. - Page 10 In multiple furnace installations, each furnace must have its own individual combustion air supply and flue gas exhaust vent. Separated combustion systems must not have a common combustion air supply or common vent unless provided with a “Special Venting” system designed by a reputable venting system provider. Figure 8 –...
-
Page 11: Operation And Safety
Operating & Safety Instructions Wiring diagram and Sequence of Operation are included in this information package for the specific control system provided on the heater module. Refer to these documents before attempting to place heater in service. 1. This furnace module does not have a pilot. It is equipped with a direct spark ignition device that automatically lights the gas burner. - Page 12 For two stage and modulating control applications, verify proper low fire adjustments as outlined in the “Sequence of Operation” sheet provided in the instruction package. Figure 10A – Honeywell VR8305Q Gas Valve Stage (Hi Fire) Manifold Stage (Lo Fire) Manifold Pressure Adjustment Pressure Adjustment (3/32”...
-
Page 13: Burner Flames
Burner Flames Prior to completing the start-up, check the appearance of the main burner flame. See Figures below for flame characteristics of properly adjusted Natural gas systems. Figure 11A Figure 11B Burner Flame @ High Fire 3.5” w.c. Manifold Burner Flame @ Start-up 1.2” w.c. Manifold Pressure Draft Inducer –... -
Page 14: Safety And Ignition Controls
Operating & Safety Controls Combustion Air Pressure Switch An air pressure switch is provided as part of the control system to verify airflow through induced draft fan (ID fan) by monitoring the difference in pressure between the ID Fan and the atmosphere. If sufficient negative pressure is not present, indicating lack of proper air movement through heat exchanger, the switch opens shutting off gas supply though the ignition control module. - Page 15 Annual Furnace Inspection 1. The duct furnace should be inspected annually by a qualified service agency. The condition of the burners, heat exchanger, draft inducer, vent system, operating controls and wiring should be determined. Check for obvious signs of deterioration, accumulation of dirt and debris and any heat or water related damage. Any damaged or deteriorated parts should be replaced before the unit is put back into service.
- Page 16 (Page left blank) Heatco Inc. 50 Heatco Court Cartersville, Ga. 30120...
