USER MANUAL
PERFORM2 CTS803
Please Keep For Future Reference
EK-EQXH-NEJX
IMPORTANT - Please Read Instructions Fully Before Assembly Or Use
These instructions contain important information which will help you get the best
from your equipment and ensure safe and correct assembly, use and maintenance.
If you need help or have damaged or missing parts,
call the Customer Helpline: 0330 124 0718 (Opening hours: Mon-Fri 9:00am-3:00pm)
or Email: customerservices@fit4home.co.uk
1
Advertisement
Table of Contents
Related Manuals for Fit4Home PERFORM2 CTS803
Summary of Contents for Fit4Home PERFORM2 CTS803
- Page 1 USER MANUAL PERFORM2 CTS803 Please Keep For Future Reference EK-EQXH-NEJX IMPORTANT - Please Read Instructions Fully Before Assembly Or Use These instructions contain important information which will help you get the best from your equipment and ensure safe and correct assembly, use and maintenance.
-
Page 2: Table Of Contents
CONTENTS Safety Information Exploded Diagram Parts List 05,06 Assembly Instructions Step 1 Step 2 Step 3 Step 4 Step 5 Step 6 Step 7 Operating the Computer Maintenance Declaration... -
Page 3: Safety Information
IMPORTANT SAFETY INFORMATION 1. Before your starting to exercise, read the manual carefully and also always keep this manual with you. 2. Before beginning any exercise program you should consult your doctor first to determine if you have any medical or physical conditions that could put your health and safety at risk or prevent any damage. -
Page 4: Exploded Diagram
EXPLODED DIAGRAM NEEDS DIAGRAM IMAGE... -
Page 5: Parts List
PARTS LIST Description Quantity Description Quantity Main frame Carriage bolt M10X L56 Front bottom tube Acorn nut φ3/8" Back bottom tube 48L/R Nylon Nut 1/2"× Right coupler bar Arc wash- Left coupler bar Computer Right pedal tube Spring wash- erφ10.5×3×φ18 Left pedal tube Washer φ16×1×2.5×φ28... - Page 6 Plastic bush- Extension tube ingφ14×12.5×φ10.1 Belt Square bushing Fan wheel axle Handlebar line Nut M10×1×B5 Solid wrench S13- 17-19 Chain wheel Socket head wrench S6 Nut M10×1×B10×φ20 Socket head wrench S8 sensor Spile Crankshaft Middle line Plastic cap Tube plug Washer Washer D8 Collar housing R...
-
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS STEP 1 FIG.1: Install the Front bottom tube (2) and Back bottom tube (3) to the Main frame (1) with Carriage bolts (46), Arc washers (49) and Acorn nuts φ3/8" (47). NEEDS DIAGRAM IMAGE STEP 2 FIG.2: Insert the Handle bar shaft (12) through the Coupler bar of left &... -
Page 8: Step 3
ASSEMBLY INSTRUCTIONS STEP 3 FIG.3: Attach the Pedals (11L, 11R) to the Pedal tubes (6L, 6R) with Bolts (44) and Nylon nuts (45). STEP 4 Insert the Handle bar (7L, 7R) to the coupler bar (5, 4), select a height setting that is comfortable to the user, and make sure both handle bars are set at the same height. -
Page 9: Step 6
ASSEMBLY INSTRUCTIONS STEP 6 Lock the spile(74)on the main frame(1) with the knob bolt(17). Install the handlebar post(79) on the spile(74) using the washer(77) and the bolt(78) STEP 7 Connect the computer wire with sensor wire,after that fix the computer(50) to the computer bracket on the handlebar post(79) with screw(83) and washer. -
Page 10: Operating The Computer
OPERATING THE COMPUTER SPECIFICATIONS TIME……………………………………………………………………00:00-99:59 SPEED(SPD)..……………………………………………0.0-99.9KM/H (ML/H) DISTANCE…………………………………………………..0.00-9999KM (ML) CALORIES……………………………………………………..0.0-9999KCAL ODOMETER(ODO)…………………………..…………..…0.0-9999KM (ML) PULSE (PUL) ……..............0 40~240BPM KEY FUNCTIONS: MODE: This key lets you to select and lock on to a particular function you want. SET: Can to proceed the data establish for “TIME” “DISTANCE” “CALORIES”“PULSE”. CLEAR(RESET): The key to reset the value to zero by pressing the key. -
Page 11: Maintenance
MAINTENANCE CLEANING The elliptical trainer can be cleaned with a soft cloth and mild detergent. Do not use abrasives or solvents on plastic parts. Please wipe your perspiration off the elliptical trainer after each use. Be careful not get excessive moisture on the computer display panel as this might cause an electrical hazard or electronics to fail. -
Page 12: Declaration
Declaration of Conformity We, Importer Fit4home Ltd Unit A, Perseverance Mills, Olive Lane, Darwen BB3 3DQ United Kingdom Declare that the product TF-8.2DA Elliptical Trainer Complies with the essential health and safety requirements of the following directive: Stationery training equipment EN ISO 20957-1:2013...
