OPERATING INSTRUCTIONS
DRIVE
SIEGENIA access control
systems
IO module
IO module smart
Window systems
Door systems
Comfort systems

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRIVE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Siegenia DRIVE

Summary of Contents for Siegenia DRIVE

  • Page 1 OPERATING INSTRUCTIONS DRIVE SIEGENIA access control systems IO module IO module smart Window systems Door systems Comfort systems...

  • Page 3: Table Of Contents

    Operating instructions SIEGENIA access control systems IO module/IO module smart Inhalt 3.5.11 WIFI (only for IO module smart) ....18 3.6. Adjustable.options.on.IO.module/. ABOUT THIS DOCUMENTATION ....4 IO.module.smart.in.combination.with. 1.1. Read.instructions .......... 4 third-party systems ........19 Producer ............4 3.6.1 Menu structure IO module/ Target group ..........

  • Page 4: About This Documentation

    Items of text with this marking in front of them are instructions.that.must.be.followed.in.the.specified. Producer order. KFV Karl Fliether GmbH & Co. KG A company of the SIEGENIA GROUP Cross reference Siemensstraße 10 (). A.cross.reference.in.the.flow.text.is.enclosed.by. 42551 Velbert brackets. Tel.: +49 2051 278-0 Fax: +49 2051 278-167 E-mail: info@kfv.de...

  • Page 5: Safety

    • Any.modification.of.the.IO.module/.IO.module.and. systems (e. g. A-opener, GENIUS A and GENIUS B/ its connected electromechanical components is Panic) and as a switching module for the SIEGENIA inadmissible. access control systems for the analogue control of third-party drives.

  • Page 6: Product Specifications

    Operating instructions SIEGENIA access control systems IO module/IO module smart Product specifications Scope of delivery Item Name piece IO module/IO module smart Termination plug Structure IO module/IO module smart Item name 12-pin.connection.terminal.strip.for.inputs.and.outputs.24.V.DC Status LED Menu LED WIFI LED (only with IO module smart) lights.up.blue:.WIFI.active...

  • Page 7: Functional.mode

    Operating instructions SIEGENIA access control systems IO module/IO module smart Functional mode 3.3.2 IO module smart • Extension of the WIFI-capable control of electrome- 3.3.1 IO module chanical.KFV.multi-point.locks.via.SIEGENIA.Comfort. • Function.upgrading.of.the.electromechanical.KFV. multi-point.locks.(slave.function) (available free of charge from Google Play Store or •...

  • Page 8: Adjustable Options On Io Module/ Io Module Smart In Combination With Genius A/B

    Operating instructions SIEGENIA access control systems IO module/IO module smart Adjustable options on IO module/ IO module smart in combination with GENIUS A/B Connection diagram with GENIUS A/B 3.4.1 Menu structure IO module/ IO module smart Out 1 - 3...

  • Page 9: Explanation.of.terms

    Operating instructions SIEGENIA access control systems IO module/IO module smart Some menu items under „System services“ and „WIFI“ can only be carried with a WIFI-capable device that is integrated in the SI-BUS system (e. g. IO.module.smart,.SIEGENIA.ACS)..The.menu.items.are.always.visible.and.no.error.message.will.appear.if.the.function.cannot.be.carried.out. The "System services" menu can be retrieved up to 10 minutes following the system start. The "WIFI" menu can be retrieved up to 5 minutes following the system start 3.4.2...

  • Page 10: Functions.switching.relay.out.1

    Operating instructions SIEGENIA access control systems IO module/IO module smart 3.4.4 Functions switching relay Out 1 LED colour in Alternating LED colours Function Description level 1 in level 2 Yellow/White Door closed and locked* Day mode = door closed Yellow/off...

  • Page 11: Functions.switching.relay.out.3

    Operating instructions SIEGENIA access control systems IO module/IO module smart 3.4.6 Functions switching relay Out 3 LED colour in Alternating LED colours Function Description level 1 in level 2 Dark blue/White Door locked / unlocked Dark.blue/off Door open / close...

  • Page 12: Functions.for.in.1

    Operating instructions SIEGENIA access control systems IO module/IO module smart 3.4.8 Functions for In 1 The.potential-free.input.contact.in.1,.e..g..for.intercom.system,.provided.by.customer,.and.for.day/night.switcho- ver.can.be.configured.via.clock.timer. LED colour in Alternating LED colours Function Description level 1 in level 2 Vanilla/White Switchover day/night mode* Vanilla/off open Vanilla/Orange Opening impulse Vanilla/Red Combination.day/night/opening.procedure.impulse...

  • Page 13: Device Services

    Operating instructions SIEGENIA access control systems IO module/IO module smart 3.4.10 Device services LED colour in Alternating LED colours Command level 1 in level 2 Light blue/White Restart the device Light.blue/off Reset.to.default.settings Light blue Light blue/Orange SW version 3.4.11 System services...

  • Page 14: Adjustable Options On Io Module/ Io Module Smart In Combination With A-Opener

    Operating instructions SIEGENIA access control systems IO module/IO module smart Adjustable options on IO module/ IO module smart in combination with A-opener Connection diagram with A-opener 3.5.1 Menu structure IO module/ IO module smart Out 1 - 3 Volume of...

  • Page 15: Volume Of The Buzzer

    Operating instructions SIEGENIA access control systems IO module/IO module smart Some menu items under „System services“ and „WIFI“ can only be carried with a WIFI-capable device that is integrated in the SI-BUS system (e. g. IO.module.smart,.SIEGENIA.ACS)..The.menu.items.are.always.visible.and.no.error.message.will.appear.if.the.function.cannot.be.carried.out. The "System services" menu can be retrieved up to 10 minutes following the system start. The "WIFI" menu can be retrieved up to 5 minutes following the system start 3.5.2...

  • Page 16: Functions.switching.relay.out.2

    Operating instructions SIEGENIA access control systems IO module/IO module smart 3.5.4 Functions switching relay Out 2 LED colour in Alternating LED colours Function Description level 1 in level 2 Light green/White Opening query Light.green/off Voltage ON* Light green/Orange No.active.error Light green *Bold italic=.default.setting...

  • Page 17: Functions.for.in.1

    Operating instructions SIEGENIA access control systems IO module/IO module smart 3.5.7 Functions for In 1 The.potential-free.input.contact.in.1,.e..g..for.intercom.system,.provided.by.customer,.and.for.day/night.switcho- ver.can.be.configured.via.clock.timer. LED colour in Alternating LED colours Function Description level 1 in level 2 Vanilla/White Open* Vanilla/off Opening impulse Vanilla *Bold italic=.factory.setting 3.5.8 Functions for In 2 The.potential-free.input.contact.in.2,.e..g..for.intercom.system,.provided.by.customer,.and.for.day/night.switcho-...

  • Page 18: System Services

    Operating instructions SIEGENIA access control systems IO module/IO module smart 3.5.10 System services LED colour in Alternating LED colours Command level 1 in level 2 Bright red/white Couple devices Light.red/off Separate devices Light red/Orange Unblock access control unit Light red/Red Reset.to.factory.settings...

  • Page 19: Adjustable Options On Io Module/ Io Module Smart In Combination With Third-Party Systems

    Connect Shield & Earth-Connection (PE) Art.No. 3509884 100-240VAC Art.No. 3509884 100-240VAC Connection diagram IO module with ACS and garage door drive Connection diagram IO module with ACS and motorised door drive 24V DC V V V V V V V V V.ADJ V.ADJ...

  • Page 20: Io Module Smart

    Operating instructions SIEGENIA access control systems IO module/IO module smart 3.6.1 Menu structure IO module/ IO module smart Out 1 - 3 Volume of Device System Out 1 Out 2 Out 3 switching In 1 In 2 WIFI services services...

  • Page 21: Functions.switching.relay.out.1

    Operating instructions SIEGENIA access control systems IO module/IO module smart 3.6.3 Functions switching relay Out 1 The.relay.Out.1.switches.when.IN.1.or.IN.2.receive.an.impulse.(e..g..from.a.button.etc.). LED colour in Alternating LED colours Function Description level 1 in level 2 Yellow/White Switches for 1 second* Yellow/off Switches for 3 seconds...

  • Page 22: Functions.switching.relay.out.3

    Operating instructions SIEGENIA access control systems IO module/IO module smart 3.6.5 Functions switching relay Out 3 The.relay.Out.3.switches.when.IN.1.or.IN.2.receive.an.impulse.(e..g..from.a.button.etc.). LED colour in Alternating LED colours Function Description level 1 in level 2 Dark blue/White Switches for 1 second Dark.blue/off Switches for 3 seconds...

  • Page 23: Functions.for.in.1

    Operating instructions SIEGENIA access control systems IO module/IO module smart 3.6.7 Functions for In 1 The.input.IN.1.receives.an.impulse.(e..g..a.button).to.switch.OUT.1.to.3). LED colour in Alternating LED colours Function Description level 1 in level 2 Vanilla/White Switches OUT 1 Vanilla/off Switches OUT 2 Vanilla/Orange Switches OUT 3...

  • Page 24: Device Services

    Operating instructions SIEGENIA access control systems IO module/IO module smart 3.6.9 Device services LED colour in Alternating LED colours Command level 1 in level 2 Light blue/White Restart the device Light.blue/off Reset.to.default.settings Light blue Light blue/Orange SW version 3.6.10 System services...

  • Page 25: Technical.specifications

    Operating instructions SIEGENIA access control systems IO module/IO module smart Technical specifications 3.7.1 IO module name Data Supply voltage 19 V DC to 32 V DC Power consumption 1.2 W Protection class Protection type IP20 (with connected plug) Operating temperature range 0°...

  • Page 26: Commissioning

    Operating instructions SIEGENIA access control systems IO module/IO module smart Commissioning Installation of SIEGENIA Comfort app f Install the due to the wide range of SIEGENIA Comfort app on your available mobile devices, we cannot guarantee that the mobile device (e. g. smart- SIEGENIA Comfort app will func- phone or tablet).

  • Page 27: Io Module In Standalone Mode

    Operating instructions SIEGENIA access control systems IO module/IO module smart f Open SIEGENIA Comfort app. f Enter user admin, enter pass- word 0000 and.confirm.with. * The term „Home WIFI“ serves as a »OK« placeholder for your own WIFI network. The name of your WIFI network should, howev- f Select IO module smart »ACS...

  • Page 28: Operation

    Operating instructions SIEGENIA access control systems IO module/IO module smart Operation Performing the adjustments on IO module/ IO module smart The.operation.of.the.IO.module/IO.module.smart.is.dependent.on.the.correct.wiring.and.coupling.of.the.components. For.this.purpose,.refer.to.the.assembly.instructions.of.the.IO.module/IO.module.smart. f If the LEDs of the IO module have already lit up, press the but- ton.briefly.to.change.to.level.1. in the menu items (see page 8).
  • Page 29 Operating instructions SIEGENIA access control systems IO module/IO module smart f Hold.down.the.menu.button.3. seconds to select a level 2 menu item. f An.acoustic.signal.sounds.as. acknowledgement. f The.selected.function.in.level.2. is.indicated.by.colour.alternating. flashing. f An.acoustic.signal.sounds.as. acknowledgement. 3 sec. f Hold.down.the.button.again.for. 3.seconds.to.save.the.setting.or. to exit the menu. f An.acoustic.signal.sounds.as.

  • Page 30: Resetting.to.the.factory.setting

    Operating instructions SIEGENIA access control systems IO module/IO module smart Resetting to the factory setting f Press.the.button.few.times.in. succession.until.the.LED.lights. up light red. f Every.press.of.a.button.is. acknowledged.by.an.acoustic. signal. f According to the menu item, another LED colour is displayed (see page 8) f Hold.down.the.menu.button.3.

  • Page 31: Maintenance

    Operating instructions SIEGENIA access control systems IO module/IO module smart f Hold.down.the.button.again.for. 3.seconds.to.save.the.setting.or. to exit the menu. f An.acoustic.signal.sounds.as. acknowledgement. f The.status.LED.flashes.green.. f The IO module/ IO module smart has been reset to the factory.settings. If.the.status.LED.flashes.red,.the. IO module/ IO module smart has not been reset to the factory settings.

  • Page 32: Eu Declaration Of Conformity With Regard To Ce Marking

    Operating instructions SIEGENIA access control systems IO module/IO module smart EU Declaration of Conformity with regard to CE marking For.our.product.IO.module/IO.module.smart,.we.confirm.that.the.general.safety.of.the.defined.product,.in.ac- cordance.with.Directive.2001/95/EC,.is.compliant.with.the.general.product.safety.and.relevant.protection.require- ments.which.are.laid.down.in.the.Council.Directives.about.electrical.and.electronic.products. The.following.listed.test.standards,.which.are.harmonised.in.the.relevant.directives,.have.been.employed.for.the. evaluation: 2014/30/EU.EMC.Directive EN 301 489-1 V1.9.2 EN 301 489-17 V2.2.1 EN 61000-3-2:2014 EN 61000-3-3:2013 EN 61000-6-1:2007 EN 61000-6-2:2005 (Part) EN 61000-6-3:2007+A1:2011 2014/35/EU.Low.Voltage.Directive...

  • Page 33: Declaration Of Conformity For Ukca Marking

    Operating instructions SIEGENIA access control systems IO module/IO module smart Declaration of Conformity for UKCA Marking For our product IO-Modul/IO-Modul smart.we.confirm.that.the.general.safety.of.the.defined.product,.in.accord- ance.with.the.General.Product.Safety.Regulations,.is.compliant.with.the.general.product.safety.and.relevant.pro- tection.requirements.which.are.laid.down.in.the.statutory.instruments.about.electrical.and.electronic.products.. The following listed test standards (designated standards) covered by the following statutory instruments have been.employed.for.the.evaluation:. Electromagnetic.Compatibility.Regulations.(2016) EN 301 489-1 V1.9.2 EN 301 489-17 V2.2.1...
