Siegenia DRIVE Operating Instructions

1 Operation with the infrared remote control
• During operation, always point the remote control
towards the LED:
– With window drives, the LED is located at the top
edge of the frame.
– With lift-slide drives, the LED is located at the
bottom edge of the slide drive SA.
• Intense solar radiation and light incidence can
reduce the range of the remote control.
• If, when a button is pressed, no function is carried
out or the function indicator does not light up, the
battery must be replaced. Used batteries must be
disposed of in an environmentally safe manner.
Insert 2 new batteries of one of the following types:
Micro, LR03 or AAA
• To operate a drive, first activate the button of the
programmed group (ALL or 1‒5).
2 Programming the infrared remote control
2.1 Window drives ‒ DRIVE axxent DK
1
Program
1,2,3,5
Delete
1,2,3,4
• Programming: Press buttons 1, 2, 3 and 5 within a
period of 3 seconds
• Deleting: Press buttons 1, 2, 3 and 4 within a period
of 3 seconds
– LED lights up green
2
1-5
• Select window 1 to 5:
– LED goes out after 10 seconds.
– The remote control is programmed in or deleted
H47.MOTS011EN-01

Operating instructions

Infrared remote control
Open
Stop
1)
all drives
Drives 1‒5
The button has no function with DRIVE axxent DK
1)
The button has no function with window drives.
2)
Note for HS drive: Pressing the button a second time cancels the timer. The
3)
lift-slide sash remains stationary. Pressing the button once more restarts the
timer. The function controls the primary sash only.
2.2 Window drives ‒ MH10
1
• Press and hold button for 5 seconds:
– 1 short acoustic signal is emitted
– 2 short acoustic signals are emitted
• Release the button
– LED flashes red
2
1- 5
• Select window 1 to 5:
– 1 short acoustic signal - The remote control is
programmed in
– 1 long acoustic signal - The remote control is
deleted
– LED goes out after 10 seconds.
12.2017
DRIVE
Intermediate
position
2)
Close
10 min
ventilation
3)
1/2
