The following instruction manual will assist you with the assembly of your virtually maintenance free Catalina Sectional Corner Chair.
DO NOT DRAG PRODUCT ON ABRASIVE SURFACES. Always use protective safety equipment where required (e.g. eyewear).
TOOLS REQUIRED: Adjustable wrench, screwdriver with #2 square bit. Use of power drill suggested.
ASSEMBLED CORNER CHAIR
NOTE: CUSHIONS SOLD SEPARATELY
KIT CONTENTS
A
B
C
D
E
GL66379-20 - ASSEMBLY INSTRUCTIONS - NOVEMBER 2020
CATALINA SECTIONAL
CORNER CHAIR
F
G
H
I
J
J
K
K
L
A.
Short Leg
B.
Left Leg
C. Corner Leg
D. Right Leg
E.
Seat Assembly
F.
Left Backrest
G. Right Backrest
H. Metal Bracket
⁄
I.
1
" Screw (4)
2
J.
2" Screw (6)
K.
Lag Screw (4)
L.
Washer (4)
IG-CATC-BS
