- Page 1 SBS-40 40' High Soccer BallStopper System Specification ® Aluminum Athletic Equipment 1000 Enterprise Drive, Royersford, PA 19468 1 of 12 Toll Free: (800) 523-5471 Phone: (610) 825-6565 www.aaesports.com...
-
Page 2: Specifications
Toll Free: (800) 523-5471 Phone: (610) 825-6565 www.aaesports.com DESCRIPTION: Concrete Footing Placement Specification NOTE: 40' HIGH BALLSTOPPER SYSTEM MODEL: CATEGORY: DATE: SBS-40 CUSTOMER 6/3/2016 CAD FILE: DWG. NO. DWN. BY: 2 of 12 SBS-40 Specifications SBS-40-C-002 N.R. Copyright 2011 Aluminum Athletic Equipment Co. - Page 3 All Hardware is RUSTPROOF Pear Clip Netting: (Stainless Steel) - Net: #AAE N367, 3-1/2" Sq. Knotted Nylon, FR, DETAIL C DBB, length to vary, 1/4" MFP Rope Border, UV protected and 1/4" cable hog tied to top of net Tensioner Kit ®...
- Page 4 DESCRIPTION Concrete Footing Specification NOTE: Grass & Turf Footing Specification MODEL: CATEGORY: DATE: 6/3/2016 CUSTOMER SBS-40 4 of 12 DRAWN BY: CAD FILE: DWG. NO. N.R. SBS-40 Specifications SBS-40-C-004 Note: **Consult Local Codes Copyright 2011 Aluminum Athletic Equipment Co.
- Page 5 Collar Assembly Aluminum Athletic Equipment (not pre-installed) 1000 Enterprise Drive, Royersford, PA 19468 Toll Free: (800) 523-5471 Phone: (610) 825-6565 www.aaesports.com When installing DESCRIPTION SBS-40 Assembly Instructions SBS-40 cable, clamp NOTE: loop goes on cut Various Collar Assemblies Cable Collar side.
- Page 6 Model No. SBS-40 Parts List ® Aluminum Athletic Equipment 1000 Enterprise Drive, Royersford, PA 19468 6 of 12 Toll Free: (800) 523-5471 Phone: (610) 825-6565 www.aaesports.com...
- Page 7 SBS-40 Post Cap Assembly Instruction pre-installed Left End Post Upper Vertical Cable Collar Assembly (see collar orientation 40.00° detail) Net Pulley 31'-0" 372" System Collar Orientation Eyebolt Detail Detail (Note: ONLY vertical cable collars should be turned away from netting)
- Page 8 SBS-40 Assembly Instruction Inner Post Post Cap pre-installed Eyebolt Detail Net Pulley System Collar Orientation Detail Installation Notes: Lower Collars: From bottom of pole slide the lower horizontal collar and and debris ring ( optional ) into Lower Horizontal position. To allow proper Cable Collar 41'-0"...
- Page 9 SBS-40 Assembly Instruction Right End Post Post Cap Upper Vertical pre-installed Cable Collar Assembly (see collar orientation detail) 40.00° Net Pulley Collar Orientation System Detail 31'-0" (Note: ONLY vertical cable 372" collars should be turned Eyebolt away from netting, this aids...
- Page 10 SBS-40 Assembly Instruction Note: Height & number of inner posts Posts to Groundsleeve may vary from what is shown. Net Hoist: Orientation (all posts) towards field of play Left End Inner Inner Right End Post Post Post Post Lower Collars:...
- Page 11 SBS-40 Assembly Instruction View from field of Play Lower Horizontal Support Cable Left End Post Inner Post Right End Post (Pear Clip Collar Assembly) (Clamped Loop End) (Crimped Loop End) Installation Notes: Refer to collar assembly diagram for further detail on collar and cable assembly.
- Page 12 SBS-40 Note: When raising net, it must be done Assembly Instruction in increments across the entire span Net Attachment Top of net Pear Clip is bound to a steel cable Cable Clamp Brass Ring Note: Hardware denoted Detail A with "B" is included in item Installation Notes: #3 "Hoist Rope"...
