- Page 1 AAE Model No. FBS-35 35' Football BallStopper System Specification ® Aluminum Athletic Equipment 1000 Enterprise Drive, Royersford, PA 19468 1 of 11 Toll Free: (800) 523-5471 Fax: (610) 825-2378 www.AAEsports.com...
-
Page 2: Specifications
Right End Post Post Refer to NFHS Guidlines for Minimum Placement Distance (AAE recommends placement of FBS 25-30 yds from endline) End Line End Zone ® Aluminum Athletic Equipment 1000 Enterprise Drive, Royersford, PA 19468 Toll Free: (800) 523-5471 Fax: (610) 825-2378 www.AAEsports.com... - Page 3 (Stainless Steel) - All Hardware is RUSTPROOF Pear Clip Netting: (Stainless Steel) - Net: #AAE N864, 3-1/2" Sq. Knotted Black Nylon, DETAIL C UV-treated, 360# tensile strength, 1/4" MFP rope border, pre-attached sewn in 3/16"dia. clear coated galvanized cable Tensioner Kit ®...
- Page 4 DESCRIPTION Concrete Footing Specification NOTE: Grass & Turf Footing Specification MODEL: CATEGORY: DATE: 4/22/2021 FBS-35 CUSTOMER 4 of 11 DRAWN BY: CAD FILE: DWG. NO. N.R. FBS-35 Specifications FBS-35-C-004 Note: **Consult Local Codes Copyright 2011 Aluminum Athletic Equipment Co.
- Page 5 Collar Assembly Aluminum Athletic Equipment (not pre-installed) 1000 Enterprise Drive, Royersford, PA 19468 Toll Free: (800) 523-5471 Fax: (610) 825-2378 www.AAEsports.com When installing DESCRIPTION FBS-35 Assembly Instructions FBS-35 cable, clamp NOTE: loop goes on cut Various Collar Assemblies Cable Collar side.
- Page 6 Model No. FBS-35 Parts List ® Aluminum Athletic Equipment 1000 Enterprise Drive, Royersford, PA 19468 6 of 11 Toll Free: (800) 523-5471 Fax: (610) 825-2378 www.AAEsports.com...
- Page 7 FBS-35 Post Cap pre-installed Assembly Instruction Left End Post Upper Vertical Cable Collar Assembly (see collar orientation detail) Net Pulley 26'-0" System 312" 40.00° Collar Orientation Eyebolt Detail Detail (Note: ONLY vertical cable collars should be turned away from netting)
- Page 8 FBS-35 Assembly Instruction Post Cap Upper Vertical Right End Post pre-installed Cable Collar Assembly (see collar orientation detail) Net Pulley System 40.00° Collar Orientation 26'-0" 312" Detail Eyebolt (Note: ONLY vertical cable Detail collars should be turned away from netting, this aids...
- Page 9 FBS-35 Assembly Instruction Posts to Groundsleeve Note: Height & number of inner posts may vary from what is shown. Net Hoist: Orientation (all posts) towards field of play Cleet: Orientation Left End Right End (all posts) Post Post away from field...
- Page 10 FBS-35 Assembly Instruction View from field of Play Lower Horizontal Support Cable Crimped Cable End (pre-assembled) Left End Post Right End Post (Clamped Loop End) (Crimped Loop End) Installation Notes: Refer to collar assembly diagram for further detail on collar and cable Cable Clamp assembly.
- Page 11 FBS-35 Assembly Instruction Net Attachment Note: When raising net, it must be done in increments across the entire span Brass Ring Top of net is bound to a Pear Clip steel cable. Note: Hardware denoted with "B" is included in item #3 "Hoist Rope"...
