QTY:
2 - Cup Pull Handles
ASSEMBLY: 1 PERSON AND 45 MINUTES
TOOLS:
1)
4mm Allen Wrench (INCLUDED)
2)
4mm Allen Drill Bit
(Be sure to FULLY SEAT bit into bolt head before turning)
3)
Phillips Head Screwdriver
*We recommend using a power driver with the drill bit if available*
BE SURE THAT LAG BOLTS ARE STARTED INTO THE HOLES ON THE FRAME RAILS
DURING ASSEMBLY. DO NOT FULLY TIGHTEN UNTIL ASSEMBLY IS LOOSELY COMPLETE
MAS90: 5043-43384
SUMMIT TRUNDLE BED HARDWARE
12
100MM DECORATIVE HEAD LAG BOLTS
4
CASTERS WITH INSERT
1
4MM ALLEN WRENCH
1
4MM POWER DRILL DRIVER
7030-00135 KIT
DESCRIPTION:
4 - 1 1/2" Combo Truss
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Living Spaces Summit 4697
Summary of Contents for Living Spaces Summit 4697
- Page 1 7030-00135 KIT MAS90: 5043-43384 SUMMIT TRUNDLE BED HARDWARE QTY: DESCRIPTION: 100MM DECORATIVE HEAD LAG BOLTS CASTERS WITH INSERT 4MM ALLEN WRENCH 4MM POWER DRILL DRIVER 4 - 1 1/2" Combo Truss 2 - Cup Pull Handles ASSEMBLY: 1 PERSON AND 45 MINUTES TOOLS: 4mm Allen Wrench (INCLUDED) 4mm Allen Drill Bit...
- Page 2 DEIII 7030-00335 LIVI NG SPACES 4697 SUMMIT TRUNDLE BED PARTS LIST: 1 - Trundle Facia w/ holes for Pull handles 1 - 74" Back Frame rail 3 - Cross slats w/ holes for Caster wheels (Note: Casters are not included for the holes in the "center" slat) 12 - 4"...
