- Page 1 Assembly Instructions 3.0m Wind-Up Parasol PWS30 IMPORTANT PLEASE KEEP THIS BOOKLET FOR FUTURE REFERENCE. THIS IS IMPORTANT INFORMATION REGARDING THE USE AND CARE OF YOUR GARDEN FURNITURE. August 2021...
- Page 2 6. Do not use any other tools other than those recommended to build this product. 7. Please do not use substitute parts. Use only additional or replacement parts supplied by Kettler. 8. In the unlikely event that this product has missing or damaged parts, please visit our website...
- Page 3 Assembly Before Assembly Step 1 Remove the cap on the finial (B) and Insert lower pole (A) into a suitable connect with the solar panel (A), then parasol base (not included). attach them to the parasol. Keep the cap for future use. Minimum weight parasol base 32kg...
- Page 4 Operating Instructions Light Switch Crank Handle Electric Socket Charging Port AC Adapter Step 3 Before opening your parasol, gently pull apart and separate the ribs into their natural open position. Turn the crank handle clockwise and continue to turn until the hub has reached the stop ring.
- Page 5 Operating Instructions OPEN CLOSE Step 4 Keep turning the crank to tilt the parasol after it is fully open. Step 5 Pull down and turn the collar in order to easily rotate the parasol 360 degrees. Stop at the desired position, release collar and the parasol firmly locks in place. CAUTION: Make sure the parasol is fully tilted.
- Page 6 Operating Instructions Tie Straps Step 6 Turn off the switch, turn the crank handle anti-clockwise until the parasol is fully closed. Use tie straps to secure parasol canopy. The parasol should be closed and the top section removed during windy weather.
- Page 7 Operating Instructions Note: • The finial (B) contains 2 x lithium batteries (2 x 2200mAh). To charge the batteries using the solar panel, press the switch to the off position during daylight. Charging time depends on the amount of sunlight; however, at least 8 hours is recommended. •...
- Page 8 • Damaged components may endanger your safety or shorten the life of the product. Replace all damaged parts immediately. Use only spare parts manufactured by Kettler. Should you wish to purchase spare parts, they can be ordered directly from: www.kettler.co.uk/shop •...
