Lumen Dynamics Group OmniCure R2000 User Manual

Uv/visible radiometer 250 – 1000 nm
Hide thumbs
Table of Contents

Advertisement

Quick Links

R2000 Radiometer
UV/VISIBLE RADIOMETER
250 – 1000 nm
USER'S GUIDE
Printed in Canada
035-00310R Rev. 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OmniCure R2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Lumen Dynamics Group OmniCure R2000

Summary of Contents for Lumen Dynamics Group OmniCure R2000

  • Page 1 R2000 Radiometer UV/VISIBLE RADIOMETER 250 – 1000 nm USER’S GUIDE Printed in Canada 035-00310R Rev. 1...
  • Page 2 32 Mb RAM 10 Mb for Software Installation 20 Mb for Data Storage SVGA video 800x600 resolution One available RS-232 Port Trademarks ® OmniCure is a trademark of Lumen Dynamics Group Inc. All other product names are trademarks of their respective owners...

  • Page 3: Table Of Contents

    Table of Contents 1 INTRODUCTION ..............3 2 CONTROL FUNCTIONS & FEATURES ......4 3 FAMILIARIZING YOURSELF WITH THE R2000 RADIOMETER ................. 6 4 USING THE R2000 RADIOMETER ......10 R2000 R ON ....10 URNING THE ADIOMETER ..........10 ALIBRATION ......
  • Page 4 „CLO‟ M ..... 38 ISPLAY NDICATES ESSAGE 7 TECHNICAL SPECIFICATIONS*........39 ............. 39 PTICAL ..........40 LECTRICAL ..........40 ECHANICAL RS-232 C OMMUNICATION ONFIGURATION ......41 NVIRONMENTAL ONDITIONS : ..... 41 EGULATORY OMPLIANCE AFETY 7.7 WEEE D (2002/96/EU) ......43 IRECTIVE ACCESSORIES..............

  • Page 5: Introduction

    It joins the Lumen Dynamics Group Inc. family of spot cure and illumination systems, offering the same high level of innovation, quality and reliability that customers have come to expect from Lumen Dynamics Group Inc.

  • Page 6: Control Functions & Features

    Control Functions & Features Features Benefits Provides accurate Versatile measurement broadband capability suitable for many measurements different light between 250-1000nm Sources Measures power or Allows for industry specific irradiance measures Optical interface Eliminates beam intensity collects light over a and radiance dependence large area Auto-ranging Maintains precision over full...
  • Page 7 Features Benefits Designed to meet IEC, Ready for use worldwide Canadian and US Standards and CE marking requirements Calibration traceable to Quality assurance NIST Calibration period of 12 Lower cost of operation months Auto turn off Extends battery life and makes operation easier RS-232 connection to Allows calibration and setup...

  • Page 8: Familiarizing Yourself With The R2000 Radiometer

    Familiarizing yourself with the R2000 Radiometer Remote Input Connector Note: For connection of optional Display cure site & cure ring radiometer only Front Keypad RS-232 Connector Rubber Boot Page 6 of 51...
  • Page 9  Carrying case  Light Guide Adapter Interfaces Lumen Dynamics Group Inc. standard size light guides to the optical input port to promote accurate light delivery into the R2000 Radiometer. The R2000 Radiometer is able to detect the output dimension of the light guide depending on the colour of the light guide adapter inserted.
  • Page 10 Pressing this button will turn the R2000 Radiometer on. RELATIVE / ABSOLUTE Each press of this button toggles between relative and absolute mode. The default setting is Absolute mode. Relative mode displays measurements percentage of a reference value. OmniCure CAL Used to calibrate and set up compatible OmniCure UV Curing Systems to a specified irradiance.
  • Page 11 Rubber Boot A protective, flexible cover that allows the radiometer to stand upright on a flat surface. The rubber boot is optional and can be removed when not desired. When the boot is utilized, the RS-232 connector and Remote Input connector are accessible by lifting flap on the right side of the boot.

  • Page 12: Using The R2000 Radiometer

    Using the R2000 Radiometer Turning the R2000 Radiometer ON The R2000 Radiometer is fitted with an ON switch located on the front keypad. Press and release the button. All segments on the display illuminate for 1 second. Note: If a light guide adapter is installed in the optical port, the display will flash the diameter of the light guide adapter for 3 sec.

  • Page 13: Using Light Guide Adapters

    measurements. The calibration is traceable to NIST and a calibration certificate is included at each calibration cycle. Calibration is authorized only by a certified Lumen Dynamics service center. When calibration is due contact Lumen Dynamics for a return authorization number. Refer to Section 9.0. Using Light Guide Adapters Each R2000 Radiometer includes two standard light guide adapters, 3mm (RED), 5mm (BLUE) and 8mm...

  • Page 14: Using Non-Standard Size Light Guides

    (i.e. 5.0). Using Non-Standard Size Light Guides In order to use non-standard size light guides with the R2000 Radiometer a custom light guide adapter is required. Contact Lumen Dynamics Group Inc. for further details. Page 12 of 51...

  • Page 15: Connecting To A Light Source

    Note: The diameter of the light guide must be entered in the PC software before the light guide is used with its custom adapter. Connecting to a Light Source Connect a light guide with corresponding light guide adapter into the optical input port on the R2000 Radiometer.

  • Page 16: Measuring In Relative Mode

    If the display is showing “ /cm ”, press the POWER/IRRAD keypad to toggle into Power mode. Measuring in Relative Mode Relative mode displays measurements percentage of a reference value. The reference is the power at the point of entering Relative mode. Select either Power or Irradiance mode from the keypad.

  • Page 17: Measuring In Absolute Mode

    Remote Input connector on the side of the R2000 Radiometer. External radiometer devices are available from Lumen Dynamics Group Inc. as custom ordered items. Press the EXTERNAL keypad button. The display will...
  • Page 18 This is indicated on the display when the EXT icon is no longer illuminated. The measurement mode is dependent on the type of sensor the external device has. For example, the R2000 Radiometer will only measure Irradiance when an external radiometer device is only able to measure Irradiance.

  • Page 19: 4.11 Storing Data

    With each press of the EXTERNAL keypad button, the display will show, Reading Reading Reading Reading Reading Internal Detector Storing Data 4.11 Storing Data The R2000 Radiometer is able to store measurements based on what is being detected at the time the STORE button is pressed.

  • Page 20: Systems

    downloaded into a Data Log as seen on the R2000 Control Panel (via the GUI software provided). stored readings can only be viewed by downloading to a Once a reading has been stored, it can not be viewed on the R2000 Radiometer display. 4.12 Interfacing with Compatible OmniCure UV Curing Systems Refer to the OmniCure Curing System User Guide.

  • Page 21: Sing The R2000 Radiometer With Apc

    system and calibration is being performed. Once the dashes cease to display the calibration cycle is complete. If the SET „Err‟ message appears it indicates that the calibration did not get completed. The calibration must be repeated. Holding the OmniCure CAL button for 5 seconds will store the current optical input into the radiometer‟s set point (this feature can be enabled or disabled via PC).
  • Page 22 the user to operate and control the Radiometer from a Installing the R2000 Control Panel Software 1) Turn on the PC to be used with the R2000 Radiometer. 2) Shut down any other Windows programs currently in 3) Insert the CD supplied with the R2000 Radiometer in the CD-ROM drive of your PC 4) Right-click your mouse on the Windows Start button and select Explore...
  • Page 23 As long as there is a connection between the PC and the Radiometer, data is automatically downloaded to the PC. A 9-pin serial cable is provided with each R2000 Radiometer. If a problem connecting occurs, a „No response from radiometer….‟ Error may be displayed. If this occurs click „OK‟...
  • Page 24 Note: This error may also appear if another program is running that is using the COM port that has been selected. The following illustrates the R2000 Control Panel: Based on the settings and data being read from the R2000 Radiometer, the information will display in the respective areas of the Control Panel.
  • Page 25  Custom Adapter Diameter  LCD Contrast Note: When data is entered into a user-defined field the background colour of the field content changes to yellow. To transfer the number into the R2000 Radiometer, press the ENTER key. If successful, the background reverts to the default colour.
  • Page 26 Light Guide Adaptor – Displays the diameter and colour of the light guide adapter being detected by the R2000 Radiometer. Setpoint – User defined; enter the desired irradiance that will be used to set the compatible OmniCure UV Curing System after the OmniCure CAL button is pressed.
  • Page 27 LCD Contrast – User defined; indicates level of contrast of LCD Display on R2000 Radiometer; 0 being the darkest and 15 being the lightest. Version – Displays software version resident on R2000 Radiometer Cal Due - Displays when next recommended calibration is due.
  • Page 28 If the RTC date/time stamp is not the same as the PC clock use the Set R2000 Radiometer Clock function under the File menu to synchronize. Status The Status frame indicates the applicable status modes of the R2000 Radiometer. Page 26 of 51...
  • Page 29 Cal Required – When checked indicates that the R2000 Radiometer is past its recommended calibration date. This is equivalent to the „CAL‟ message that appears on the R2000 Radiometer‟s display. Low Battery – When checked indicates that the battery is low and should be replaced. This is equivalent to the „BAT‟...
  • Page 30 Menu Functions To operate and control the R2000 Radiometer from the PC, select desired menu functions located across the top of the R2000 Control Panel. Display Select the Display menu and then select the desired mode of Power, Irradiance, Absolute or Relative. Selected options are indicated as checked boxes in the Display frame.
  • Page 31 Lockout Select Lockout menu option to disable certain features or functionality from the front keypad of the R2000 Radiometer. Select from the available list in the pull-down menu. The selections that are checked are indicated in the Lockout frame. If a box is checked, this means that this function will not operate from the front keypad of the R2000 Radiometer.
  • Page 32 Get LGA In the event that the size of the light guide adapter must be re-detected remotely, it can be obtained from the Get LGA menu option at the top of the screen. Selecting this will re-detect the colour of the light guide adapter and hence the size of the light guide installed in the R2000 Radiometer.
  • Page 33 Select Log Readings During OMNICURE CAL to log each calibration point into the Data Log during a calibration cycle with a compatible OmniCure UV Curing System. The following is a sample screen shot of the Data Log, Page 31 of 51...
  • Page 34 Power Down Select this menu option to power down the R2000 Radiometer. Page 32 of 51...

  • Page 35: Glossary Of Symbols And Safety Precautions

    Glossary of Symbols and Safety Precautions CAUTION – RISK OF DANGER Consult accompanying documents CAUTION! Never look into the light emitting end of a light guide. The light could severely damage the cornea and retina of the eye if the light is observed directly.
  • Page 36 SAFETY PRECAUTIONS: WARNING! Should the R2000 Radiometer be used in a Lumen Dynamics Group manner not specified by Inc. the protection provided by the equipment may be impaired. WARNING! The R2000 Radiometer is supplied with a lithium battery. Lithium batteries present a potential fire, explosion or severe burn hazard.

  • Page 37: Troubleshooting

    Troubleshooting Error Messages Display Indicates ‘Adc’ Message If an Adc message appear on the display it indicates that there is an internal problem with the unit during power up. If this occurs, it is recommended that the R2000 Radiometer be serviced. See Section 9. Display Indicates ‘BAT’...

  • Page 38: Isplay Ndicates Al Essage

    Place the R2000 Radiometer back into the rubber boot if desired. Used batteries are not to be discarded. Return to the nearest authorized Lumen Dynamics Group Inc. service center for disposal/ re-cycling. Use appropriate safety measures found in Section 5.

  • Page 39: Isplay Ndicates „Lg" Message

    If the SET icon is displayed with the Err message it indicates that a SET function was not completed successfully. If the EXT icon is illuminated on the display with the Err message displayed indicates that R2000 Radiometer was unable to communicate with an external adapter.

  • Page 40: Lga" Message

    Display Indicates ‘LGA’ Message This message as illustrated below will appear when the R2000 Radiometer is unable to detect the colour of the light guide adapter. If this message appears it is recommended that the light guide adapter be cleaned or replaced.

  • Page 41: Technical Specifications

    7 Technical Specifications* Optical Wavelength Range: 250-1000 nm Maximum Range: Power: 1mW – 15W Irradiance: 2mW/cm – 475W/cm Resolution: Power Range: 0.007-1.999mW 0.01mW 2.00-19.99mW 0.01mW 20-199.9mW 0.1mW 200-1999mW 2.00-19.99W 10mW Accuracy: ± 5% typical, ± 10% maximum Auto-ranging: Power: 1 – 999 mW, 1 –...

  • Page 42: Electrical

    Electrical Battery Type: 3.6 volt Lithium, non-rechargeable 2.2 Ah I/O Ports: Connect only to RS-232 Pin 1 (Shield) – GND equipment that Pin 2 (Ring) – Tx is IEC 950 Pin 3 (Tip ) – Rx compliant Remote Input Port: 6-Pin Mini-DIN connector (use only with optional Cure Site &...

  • Page 43: Environmental Conditions

    Environmental Conditions Operating Environment Conditions Installation Category II Pollution Degree 2 Ambient Temperature: 10 to 35 degrees Celsius Relative Humidity: 15% to 95% (non-condensing) Atmospheric Pressure: 700 to 1060 hPa Altitude: 2000 meters (maximum) Transport and Storage Conditions Temperature: -10 to 60 degrees Celsius Relative Humidity: 10% to 100% (non- condensing)
  • Page 44 Electromagnetic Compatibility: EN 61326-1: 2001/ A1/ A2 Electromagnetic Compatibility Immunity Testing-Measurement, Control and Laboratory Equipment CE Marking: Council Directive 73/23/EEC Low Voltage Directive Council Directive 89/336/EEC EMC Directive Council Directive 2002/96/EC WEEE Directive Page 42 of 51...

  • Page 45: Weee Directive (2002/96/Eu)

    China RoHS The following table contains substance information for the Omnicure R2000 as required by China RoHS regulations. 有毒有害物质名称及含量的标识格式 有毒有害物质或元素 六价 多溴 多溴二 部件名称 汞 铅 镉 苯醚 铬 联苯 ） ） ） (Cr6+) (PBB) (PBDE） 显示器印刷电 ○ ○ ○...
  • Page 46 The symbol above indicates that this product should not be disposed of along with municipal waste, that the product should be collected separately, and that a separate collection system exists for all products that contain this symbol within member states of the European Union.
  • Page 47  Consult the dealer or an experienced radio/TV technician for help WARNING Changes or modifications not expressly approved by Lumen Dynamics Group Inc. could void the user‟s authority to operate the equipment. Page 45 of 51...

  • Page 48: Accessories

    Accessories Lumen Dynamics Group Inc. carries a full line of replacement parts, supplies and accessories for the R2000 Radiometer. team light-based technology experts recommend light delivery solutions for a range of manufacturing, illumination and biomedical applications. We also welcome custom requests for unique light delivery requirements.
  • Page 49 Optional Adapters Optical accessories provide solutions to a wide range of situations. Optical accessories include the Proximity Measurement Adapter and the optional Lamp Output Adapter. These adapters expand the range of measurement geometries that can be accommodated. 5mm Proximity Adapter Reorder No.

  • Page 50: Warranty

    Lumen Dynamics Group Inc. Service Centre within 30 days from the original date of receipt. Lumen Dynamics Group Inc. will repair or replace these reported defects free of charge for a period of up to 2 years from the original date of receipt.
  • Page 51 In the case of damage caused by wear and tear, careless handling, neglect, by the use of force or in the case of interventions and repairs not carried out by an Lumen Dynamics Group Inc. Authorized Service Center, the guarantee ceases to be valid.
  • Page 52 Page 50 of 51...
