Artist Guitars BAH200 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BAH200
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAH200 and is the answer not in the manual?

Questions and answers

Related Manuals for Artist Guitars BAH200

Summary of Contents for Artist Guitars BAH200

  • Page 1 BAH200 MANUAL...

  • Page 2: Important Safety Instructions

    BAH200 IMPORTANT SAFETY INSTRUCTIONS • Read these instructions. • Keep this instruction manual. • Pay close attention to all the warnings. • Follow all instructions. • Do not use near water. • Do not, under any circumstance, expose to any dripping or splashing liquid.
  • Page 3 BAH200 • Excessive sound pressure from earphones and headphones can cause hearing loss. • No naked flame sources, such as candles should be placed on or near the apparatus • If needed, lift amplifier with care. Use a trolley as needed, but caution is advised to prevent the trolley tipping over.
  • Page 4 BAH200...
  • Page 5 There is also built-in Thermal and Over Current Protec- tion. Not only for gigs, the BAH200 also has an aux input to assist you with practice. Plug in your media device and play along to your favourite back- ing tracks or songs! Please note: This is an amplifier head only - it does not have any speakers.

  • Page 6: Front Panel

    BAH200 FRONT PANEL 1. Input This is where you plug in your bass. 2. Mute Button This button silences the amp, allowing you to safely plug in, and unplug the bass without any loud pops or audio distortion. The light above shines red when the amp is muted.
  • Page 7 BAH200 6. Low-Mid EQ Control Dictates the Lower side of your middle-frequency register of the amplifier. Turning this up will make your Bass guitar sound fatter, ideal for Rock and Metal style Bass tone. Conversely reducing the amount of Low-Mid in your tone will result in a scooped, hollower Bass guitar sound for most Metal and Funk styles of Bass playing.

  • Page 8: Back Panel

    BAH200 13. Headphone Output This is where you plug headphones in to hear your bass sound directly through your headphones. This cuts the speaker output signal and allows for quiet practice just through your headphones. BACK PANEL 1. Power Switch This switch powers up the amplifier.

  • Page 9: Ground/Lift Switch

    BAH200 5. Direct Output Level This determines the level of the direct output. 6. Send and Return The effects loop send and return allows you to plug in pedals but have them either after the preamp in the signal chain or before, depending on the position of the Pre/Post switch (see 7).

  • Page 10: Technical Specification

    BAH200 12. /4' Speaker Output This output is used to connect the amplifier head to a speaker box. This connection is for speaker stacks that use a 1/4 inch connector. TECHNICAL SPECIFICATION Type: Class D Power Output: 200w RMS Power Requirement: 100-120VAC or 220-240VAC; 50Hz/60Hz 220w (Included) Weight: 2.5Kgs...

  • Page 11: Additional Information

    BAH200 ADDITIONAL INFORMATION • This amplifier is designed for bass guitars. Using it with a guitar won’t damage the speaker, but it won’t sound ideal. • This Amplifier requires a speaker cabinet to be played with volume. It can be used alone through headphones, but will need a speaker to be audible without headphones.
