  • Page 1 M A N U A L Maestro City Electro...
  • Page 2 © ELIET Copyright 2018 ELIET. All rights reserved. All textual material, drawings, figures, diagrams, graphs, ets., included in this ELIET booklet are protected by copyright and also by other intellectual property rights. Nothing from this information may be copied for commercial goals or distributed and/or changed or reposted for other goals.

  • Page 3: Introduction

    1. Introduction 1.1 Carefully read this user manual ELIET machines are designed for safe and reliable use if they are operated in accordance with the instructions given. Carefully read these operating instructions before using the machine. Failure to observe this may result in personal injury or damage to the equipment.

  • Page 4: Welcome

    Welcome to the family of ELIET customers. We would like to thank you for the confidence that you have placed in ELIET and we are con- vinced that you have purchased the very best machine. The operating life of your ELIET machine depends to a great extent on how you care for your machine.

  • Page 5: Table Of Contents

    4. Table of contents 1. Introduction ............................ 3 1.1 Carefully read this user manual ....................... 3 1.2 Identification data – ELIET MAESTRO City ................... 3 2. Warranty ............................3 2.1 Registration of your machine ........................3 3. Welcome ............................4 4. Table of contents ...........................5 5.
  • Page 6 11.3.5 General lubrication treatment ....................43 12. Winterizing the machine ......................44 13. Equipment Specifications ......................45 14. EC Declaration of Conformity ....................46 15. Warranty conditions ........................47 16. Annexxes ........................... 49 16.1 Hazard analysis ............................49 16.2 Opening and closing the shredding chamber ................50 16.2.1 Opening the shredding chamber .....................

  • Page 7: Operator Safety Warnings

    5. Operator safety warnings A number of symbols are used in this user manual top provide additional information and to highlight dangers. 5.1 For your information For your information: This symbol is used to draw you attention to specific information and/or actions, or to denote where you can find additional information relating to the subject.

  • Page 8: Main Parts

    6. Main parts To fully understand the contents of this operator’s manual, you need to be thoroughly familiar with the terminology used for the descriptions. In this chapter you can find a set of parts identified by name. It’s a good idea to take time to study the machine beforehand for an improved understanding of the descriptions given in this user’s manual.

  • Page 9: Engine

    6.2 Engine electric 3000W / 230V...
  • Page 10 FRONT For your information: Your ELIET Dealer is at your service, ready to provide you with maintenance or advice to keep your ELIET machine operating at peak efficiency at any one time. Parts and lubricants can be obtained from your ELIET Dealer. These service parts are manufactured to the same stringent accuracy and degree of crafts- manship as the original equipment.

  • Page 11: Safety Regulations

    7. Safety regulations 7.1 Safety messages A. The starting button is green and provided with the “I” sign that is universally known as representing “on”. The stopping button is red and provided with the “O” sign that is universally known as represen- ting “off”.
  • Page 12 These icons are pictured on the left side of the feed hopper. When performing a maintenance to the ma- chine, always turn off the engine. Put the switch on the engine to the OFF-position, in order to provide accidentally turning on the engine. Do not allow third parties near the machine while performing a maintenance.
  • Page 13 60 KG SOUNDPOWER : 110 dB(A) • Weight • Guaranteed A-weighted sound power level ELIET NV ZWEVEGEMSTRAAT 136 B-8553 OTEGEM BELGIUM WWW.ELIET.BE MADE IN EUROPE Moreover, the sticker indicates all manufacturers’ information. The CE mark on the label testifies the conformity...

  • Page 14: Safety Features

    7.2 Safety features The collecting bag: The collecting bag is located on the underside of the machine. Remove the collecting bag and the motor automatically shuts off. In so doing, the collecting bag prevents you from inserting your hands into the rotating shred knives.
  • Page 15 Rugged construction: The robust construction not only adds to the long operating life of the machine but also provides extra user safety whenever there is an unforeseen emergency. Sound absorption: The double-walled acoustic housing accommodating the knife drum gives excellent noise reduction whilst shredding, therefore, minimis- ing noise nuisance for both the operator and the surroundings.

  • Page 16: General Safety Precautions

    7.3 General Safety Precautions • The owner must keep the manual during the complete service life of the machine. It serves as a reference for the user, therefore, enabling the machine to be used and maintained in accordance with the correct instructions. (This manual is part of the machine) •...
  • Page 17 Children and animals must be kept well away from the machine. • ELIET recommend that the machine should not be lent to others. However, if this is done, only lend it to persons who are familiar with the machine. Always ensure that the user is aware of the potential hazards, and ensure that he reads the manual before using the machine.
  • Page 18 • When parts must be renewed as a result of wear or failure, you must always request genuine ELIET service parts from your ELIET dealer. This is important in the interests of your own safety. (Find an official ELIET dealer near you by visiting .) Handle the machine in an environmentally conscious manner: a) Do not run the machine unnecessarily without being at work.

  • Page 19: Guidelines Related To The Electric Machines

    7.4. Guidelines related to the electric machines On machines powered by an electric motor, the following guidelines must be observed as well. A. Related to the Maestro City Electro Below we supply the specific features of the motor: cos ϕ : 0.96 Capacitor: 40 µF...

  • Page 20: Dealer Preparation

    5 (five) operating hours. When the machine has been removed from its packaging, it is still not completely assembled. Your ELIET Dealer is expected to complete these preparation steps. Following are a few guidelines.
  • Page 21 • First apply some grease to the shaft from the wheel holder. Now slide the wheels with stem facing outside on the shaft and secure them using the starlock fasteners. • • Next, slide the wheel holder into the machine chassis. Push the wheel holder in even increments until the frame tubes are a sliding fit over the vertical tube ends of the wheel holder.
  • Page 22 • Place the handle in the feed hopper, align the upper holes. In- sert a M6 bolt with flat washer true the feed hopper and handle. Slide a nylon strap on the bolt and screw the bolt into the rub- ber silent bloc.

  • Page 23: Operating Instructions

    9. Operating instructions 9.1 Preliminary checks Caution: Before commencing the work, it is recommended to get into the habit of checking the following points. Checklist 1. Satisfy yourself that the shredding knives are firmly in place and in good condition. If they need to be sharpened, this must be done first.

  • Page 24: Preparing The Operating Area

    9.2 Preparing the operating area • Clear the area first where the machine is to be used. In addition, the paths along which the plant trimmings are removed, must be kept clear, thus releasing the operator from the worries of tripping up over them. The operator must also ensure that his safety is not compromised. •...

  • Page 25: During The Work

    • If the equipment is primarily used for shredding leaves or damp material using the standard sieve screen, the chances , the chances are that he screen will clog. To avoid this Eliet has a special screen-option item MA 001 052 001 available for purchase.

  • Page 26: Emptying The Collecting Bag

    REMOVING THE Collecting BAG = MOTOR SHUT OFF Normally, the engine shuts off if the feed hopper is loosened. If this is not the case, the machine operator will turn off the machine manually with the switch on the motor. The defect must be fixed immediately before proceeding the work.

  • Page 27: What To Do About Motor Stalling

    Check whether the collection box has been correctly positioned and whether the window elements have been correctly mounted. If the machine does not want to start up after chec- king these two points, consult your official ELIET dealer. (Find an authorized ELIET dealer near you by visiting www.eliet.eu.) Perform the work more carefully in the future in order to avoid jamming of the machine.

  • Page 28: Cleaning The Machine

    • Using a dry cloth, remove any dirt from the chassis. Pay special attention to places where stickers with safety messages are displayed. • Decals used to indicate safety messages, that are no longer legible must be immediately replaced. Obtain these original decals from your ELIET Dealer. Caution: Wear proper apparel when cleaning. Gloves are required.

  • Page 29: Transporting The Machine

    10. Transporting the machine • Make sure to clear the shredding chamber before moving the machine. Make sure the infeed opening is free of branchy material. • When moving the machine over greater distances (over 2m - 8ft), always take care to turn off the engine.
  • Page 30 • Use slip resistant ramps to load the machine into a van or a trailer. Ensure that those are well secured to the vehicle or trailer. • Assure yourself the parking brake of the vehicle is on before loading the machine. •...

  • Page 31: Maintenance

    • For your own safety, only genuine service parts must be installed on the ELIET machines. Perform maintenance in a room intended for this purpose. This area must have the following features.

  • Page 32: Maintenance Schedule

    ELIET dealer for a maintenance each year. Your ELIET dealer is always at your service for maintenance and advice. He stocks genuine ELIET service parts and lubricants. His staff can always obtain advice and service from ELIET, so that they can provide you with the best after-sales service.
  • Page 33 50). Pay particular attention to the following: Garden waste chipping with the ELIET chipping system takes place in two steps. We first have the contact of the blades with the garden waste when chopping takes place where the cutting block can be found.

  • Page 34: Sharpening The Blades

    (“read § 11.3.4 Reversing and changing chipper blades” on page 37 where the rules are explained.) 11.3.3 Sharpening the blades. Correct and timely Sharpening of the chipping blades will extend blade life. (ELIET recommend the following: Grind after at least every 10 working hours.) Preparatory warnings •...
  • Page 35 • Remove the blade shaft from the machine to grind blades (see annex 3). • For safety’s sake, firmly clamp the blade shaft (i.e. In-between a bench vice) and ensure that this cannot twist, move or fall unexpectedly during maintenance and, thus, injure someone. For your information: The blades do not have to be disassembled for Sharpening.
  • Page 36 This will ensure for very short grinding times and you will always have the best possible cutting edge. (ELIET recommend the following: Every 10 working hours.) • Avoid grinding at the same location for a longer period of time.

  • Page 37: Reversing And Changing Chipper Blades

    Any entitlement to claim on the guarantee will be excluded in case of damage or consequential damage that occurs due to faulty maintenance of the blades. Consult your official ELIET dealer for advice if required. 11.3.4.1 Work method for reversing the blades...
  • Page 38 There are a few rules that must be respected for revers- ing or replacing the blades. First we will examine in detail the construction of the blade shaft to understand the logic behind the rules: • A Maestro City blade shaft has been constructed from two identical blade discs that each contain 6 blades.
  • Page 39 Remove and refit one blade at a time. This ensures that reversal is performed in an orderly manner. TIP: There are 36 bolt connections in each blade shaft. ELIET recommend using a pneumatic ratchet wrench to quickly loosen these. Place a ring spanner on the bolt head and loosen the nut using the ratchet wrench ratchet.

  • Page 40: Work Method For Replacing The Blades

    11.3.4.2 Work method for replacing the blades New sets of blades are available form your ELIET dealer under the following part number: BU 401 100 102 • Stop the machine and disconnect the power supply extension cable from the machine.
  • Page 41 You may not simply randomly reinstall the blades. A specific order needs to be respected. • Number the blade positions on the blade disc from 1 to 6 to ensure mistakes cannot be made. Start numbering with the right blade position that shows a notch and number clockwise (as viewed from the tightening side).
  • Page 42 • Follow the same procedure for the second blade plate. • Perform a check to verify whether the blades have been installed correctly: Apply the following rules: 1. All blades (2 per blade disc that have been positioned at an angle on the blade disc and are oriented towards the wall of the shredding chamber must always be pointing with their back (B)

  • Page 43: General Lubrication Treatment

    11.3.5 General lubrication treatment ELIET is committed to using high-quality materials that extend a machine’s life cycle despite the sometimes extreme work circumstances in which chippers are being used. For this reason, special lubrication products have already been applied in the factory.

  • Page 44: Winterizing The Machine

    • If the machine is to be stored outside, it must be well protected with a tarpaulin. • Ensure that water does not directly fall onto the machine. ELIET strongly recommend that the machine is stored at a location that is well protected from the weather, etc.

  • Page 45: Equipment Specifications

    Maestro City Shreddable timber diameter 35 mm - 1” 3/8 diameter Chopping speed (cuts/min) 36.000 Capacity (wheelbarrows/h) Blades 12 ELIET Resist knives reversible Infeed height 1050 mm / 41” Collecting box capacity 60 litres / 16 US gallon Storage dimensions 740x650x910 mm / 29x26x36”...

  • Page 46: Ec Declaration Of Conformity

    “EN 13683:Garden Equipment –Integrally powered shredders/chippers –Safety” ELIET machine factory hereby declares that after performing a hazard analysis, it is fully aware of the potential hazards and risks associated with the machine. In this knowledge, the necessary steps have been taken in line with Machine Directive 2006/42/EG in order to ensure absolute operator safety for the operator, when the machine is used correctly.

  • Page 47: Warranty Conditions

    • If it turns out that the defect was caused by acting against the instructions or advice of the user manual in. • When the defect occurs after a repair by an unofficial ELIET dealer or a repair using parts that are not original ELIET parts.
  • Page 48 • Step 4: The dealer then orders the parts needed to perform the repairs. Next, the dealer faxes the order form together with the completed warranty form. • Step 5: The warranty form should be stapled to the purchase invoice and mailed to ELIET or an importer/agent of ELIET.

  • Page 49: Annexxes

    16. Annexxes 16.1 Hazard analysis Below you will find a list of dangers and risks that are linked to storing away, transporting or using the chipper. Take note of these dangers and avoid these risks by following the instructions contained in this manual. Be aware that it is not just the user who runs a risk but also third par- ties can be exposed to these risks.

  • Page 50: Opening And Closing The Shredding Chamber

    16.2 Opening and closing the shredding chamber 16.2.1 Opening the shredding chamber First remove the collecting bag out of the machine to get access to the sieve Turn the lever (1) to loosen the lock on the screen. If the lever is completely loose, press on the handle.

  • Page 51: Removing And Reinstalling The Blade Shaft

    16.3 Removing and reinstalling the blade shaft Caution: Always switch off the engine prior to removing the blade shaft. Warning: To perform this maintenance, you are exposed to the blades. Protect yoursefl against the risks and wear safety gloves. Before removing the blade axle, slide the collecting bag out of the machine and remove the sieve (“read §...
  • Page 52 Now you can loosen the engine mounting plate from the frame. To do so, loosen the four M8 bolts completely. The engine and its fixing plate are no longer attached to the chassis. Once the clamping force is gone, you can slide the blade axle from the crankshaft. Grab the blade axle between two blade plates at it’s core, en hold it up.

  • Page 53: Dismantling The Infeed Hopper

    Place the clamping bolts back in the engine plate. Turn the bolts till the moment where there is no tension on the bolts. Now, see if the blade shaft is aligned relative to the Central nylon support block. The air gap between the blade shaft and nylon support block must be equal everywhere.
