The WattBox Trigger provides users with an easy way to cycle power on any or
all of the outlets on a WB-IP device.
Package Contents
• WattBox Trigger (normally open, momentary closed) switch with adhesive
backing
Installation
Position the switch in the desired location, then connect to the "REMOTE
TRIGGER" port on the WattBox using the phoenix connector included with the
IP device. Then log into the WB-IP interface to enable the trigger port and select
which outlets to power cycle.
Phoenix
connector
INSTALL GUIDE
WB-ACC-TRIGGER
Remote trigger
on the WattBox
Extend wiring
up to 45'/13.7m
using Cat5 or other
conductors 24AWG
or larger. Wires can
be connected either
way (no polarity).
